OPEL SIGNUM 3.2

OPEL SIGNUM

Z02Z32L · 3.2

Description

Modification: 3.2
Chassis ID: Z02Z32L
Dates releasing: 2004.11~
Base price, ¥: TA-Z02Z32L
Body size: 4635x1800x1460
Interior (LxWxH): 1860x1380x1180
Wheelbase: 2830
Track f/r: 1520mm/1515mm
Full weight, kg: 1590
Body type: Wagon
Doors / seats: 5 door / 5

Safe equipment

Driver's air bag: ✓
Front passenger air bag: ✓
Side airbags: ✓
ABS: ✓
TRC: ✓
Belts w/ tensioner: ✓
Belts w/ effort limiter: ✓
Belts w/ holding: ✓
Child-seat fixation: ×
Safety planks: ✓
Brake assist: ✓
Energy-absorbing body: ×
EBD: ✓
Anti-theft device: ✓
Additional equipment: ESPプラス(エレクトロニックスタビリティ PRO グラム) CBC(コーナリングブレー&#1246

Comfort

Air conditioner: Full Auto
Power window: ✓
Central switch: ✓
Steering column length: ✓
Steering column height: ✓
Cruise control: ✓
Leather steering wheel: ✓
Leather seats: —
Power front seat: ✓
Power rear seat: ×
Wood panel: ×
Sunroof: ◯
Alloy wheels: 17 inches standard
Folding seat: split
Glass w/ UV filter: ×
Toned glasses: ×

Engine

Model: Z32
Type: V-type 6 cylinder DOHC
Bore x stroke, mm: 87.5x88.0
Engine size, cc: 3174
Compression ratio: 10.0
Fuel injection: 電子制御燃料噴射
Max power, hp/rpm: 211ps(155kW)/6200rpm
Max torque, Nm/rpm: 30.6kg m(300N m)/4000rpm
Supercharger: ×
Fuel tank, liters: 60 l
Fuel: Unleaded premium gasoline
Fuel consumption, l/100km: 10.9

Steering & suspension

Steering: Power assist equipped rack&pinion
Front suspension: McPherson Strut
Rear suspension: マルチリンク(4リンク)
Front brake: Ventilated disk
Rear brake: Ventilated disk
Front wheel: 215/50R17
Rear wheel: 215/50R17
Min turn diameter, m: 5.6

Gearbox

Number of stages: 5AT
Drive: FF
LSD: ----

Exterior equipment

Front fog lights: ✓
Rear fog lights: ✓
Xenon: ✓
Extra front lights: ×
Spoilers (f / r): × / ×
Wiper: ✓

Navigation & sound

Navigation: ◯
Navigation device: DVD
Audio: AM/FMラジオ
CD player: 連装

Gear ratios

CVT	1	2	3	4	5	6	7	Rev	Main
—	4.685	2.942	1.923	1.301	1.000	—	—	—	3.177

Available colors

black / Other blackwhitegreenMaroon (brown)OliveNavy blue / Other Navy bluePurpleAshesYellowYellow-greenBlack (P)MagentaSilver / Other SilverRedBlueDark cyanPearlGold / Other Gold
