SAAB 93 SERIES 9-3 SE 2.0T

SAAB 93 SERIES

DB205 · 9-3 SE 2.0T

Description

Modification: 9-3 SE 2.0T
Chassis ID: DB205
Dates releasing: 2002.2~
Base price, ¥: GF-DB205
Body size: 4650x1710x1475
Interior (LxWxH): 1790x1400x1150
Wheelbase: 2605
Track f/r: 1450mm/1440mm
Full weight, kg: 1410
Body type: Sedan
Doors / seats: 5 door / 5

Safe equipment

Driver's air bag: ✓
Front passenger air bag: ✓
Side airbags: ✓
ABS: ✓
TRC: ×
Belts w/ tensioner: ×
Belts w/ effort limiter: ✓
Belts w/ holding: ✓
Child-seat fixation: ×
Safety planks: ✓
Brake assist: ×
Energy-absorbing body: ×
EBD: ×
Anti-theft device: ✓
Additional equipment: ×

Comfort

Air conditioner: Full Auto
Power window: ✓
Central switch: ✓
Steering column length: ×
Steering column height: ×
Cruise control: ×
Leather steering wheel: ✓
Leather seats: —
Power front seat: ✓
Power rear seat: ×
Wood panel: ✓
Sunroof: ◯
Alloy wheels: 15 inches standard
Folding seat: split
Glass w/ UV filter: ×
Toned glasses: ×

Engine

Model: ----
Type: water cooling inline 4 cylinder DOHC 16-valves IC-turbo
Bore x stroke, mm: 90.0x78.0
Engine size, cc: 1984
Compression ratio: ----
Fuel injection: トリオニック
Max power, hp/rpm: 150ps(110kW)/5500rpm
Max torque, Nm/rpm: 24.5kg m(240N m)/1800rpm
Supercharger: IC turbo
Fuel tank, liters: 68 l
Fuel: Unleaded premium gasoline
Fuel consumption, l/100km: 10.6

Steering & suspension

Steering: Power assist equipped rack&pinion
Front suspension: McPherson
Rear suspension: トレーリングアーム
Front brake: Ventilated disk
Rear brake: disk
Front wheel: 195/60R15 88V
Rear wheel: 195/60R15 88V
Min turn diameter, m: 5.3

Gearbox

Number of stages: 4AT
Drive: FF
LSD: ----

Exterior equipment

Front fog lights: ✓
Rear fog lights: ✓
Xenon: ×
Extra front lights: ×
Spoilers (f / r): ✓ / ✓
Wiper: ✓

Navigation & sound

Navigation: ×
Navigation device: It is not
Audio: AM/FMラジオ
CD player: 単装

Gear ratios

CVT	1	2	3	4	5	6	7	Rev	Main
—	3.671	2.098	1.391	1.000	—	—	—	—	4.021

Available colors

blackwhite / Other whitegreen / Other greenMaroon (brown)OliveNavy blue / Other Navy bluePurpleAshes / Other AshesYellowYellow-greenBlack (P)MagentaSilver / Other SilverRed / Other RedBlue / Other BlueDark cyanPearlGold / Other Gold
