SAAB 93 SERIES 9-3 SPORT ESTATE AERO

SAAB 93 SERIES

FB284 · 9-3 SPORT ESTATE AERO

Description

Modification: 9-3 SPORT ESTATE AERO
Chassis ID: FB284
Dates releasing: 2005.11~
Base price, ¥: GH-FB284
Body size: 4655x1760x1540
Interior (LxWxH): ----x----x----
Wheelbase: 2675
Track f/r: 1525mm/1505mm
Full weight, kg: 1630
Body type: Wagon
Doors / seats: 5 door / 5

Safe equipment

Driver's air bag: ✓
Front passenger air bag: ✓
Side airbags: ✓
ABS: ✓
TRC: ✓
Belts w/ tensioner: ✓
Belts w/ effort limiter: ✓
Belts w/ holding: ✓
Child-seat fixation: ×
Safety planks: ✓
Brake assist: ×
Energy-absorbing body: ×
EBD: ✓
Anti-theft device: ✓
Additional equipment: ESPプラス(エレクトロニックスタビリティ PRO グラムプラス) CBC(コーナリングブ

Comfort

Air conditioner: Full Auto
Power window: ✓
Central switch: ✓
Steering column length: ×
Steering column height: ×
Cruise control: ✓
Leather steering wheel: ✓
Leather seats: —
Power front seat: ✓
Power rear seat: ×
Wood panel: ×
Sunroof: ◯
Alloy wheels: 18 inches standard
Folding seat: split
Glass w/ UV filter: ×
Toned glasses: ✓

Engine

Model: ----
Type: water cooling V-type 6 cylinder DOHC 24-valves IC-turbo
Bore x stroke, mm: 89.0x74.8
Engine size, cc: 2792
Compression ratio: ----
Fuel injection: トリオニック
Max power, hp/rpm: 250ps(184kW)/5500rpm
Max torque, Nm/rpm: 35.7kg m(350N m)/2000rpm
Supercharger: IC turbo
Fuel tank, liters: 58 l
Fuel: Unleaded premium gasoline
Fuel consumption, l/100km: 11.9

Steering & suspension

Steering: Power assist equipped rack&pinion
Front suspension: McPherson
Rear suspension: Independent suspension
Front brake: Ventilated disk
Rear brake: Ventilated disk
Front wheel: 225/45R18
Rear wheel: 225/45R18
Min turn diameter, m: 5.8

Gearbox

Number of stages: 6AT
Drive: FF
LSD: ----

Exterior equipment

Front fog lights: ✓
Rear fog lights: ✓
Xenon: ✓
Extra front lights: ×
Spoilers (f / r): ✓ / ✓
Wiper: ✓

Navigation & sound

Navigation: ×
Navigation device: It is not
Audio: AM/FMラジオ
CD player: 連装

Gear ratios

CVT	1	2	3	4	5	6	7	Rev	Main
—	4.148	2.370	1.555	1.154	0.859	0.685	—	—	3.393

Available colors

black / Other blackwhite / Other whitegreen / Other greenMaroon (brown)OliveNavy blue / Other Navy bluePurpleAshes / Other AshesYellowYellow-greenBlack (P)MagentaSilver / Other SilverRed / Other RedBlue / Other BlueDark cyanPearlGold / Other Gold
