SUBARU LEGACY TX TYPE S

SUBARU LEGACY

BD5 · TX TYPE S

Description

Modification: TX TYPE S
Chassis ID: BD5
Dates releasing: 1997.9~
Base price, ¥: E-BD5
Body size: 4605x1695x1405
Interior (LxWxH): 2010x1415x1155
Wheelbase: 2630
Track f/r: 1460mm/1455mm
Full weight, kg: 1290
Body type: Hardtop
Doors / seats: 4 door / 5

Safe equipment

Driver's air bag: ✓
Front passenger air bag: ◯
Side airbags: ×
ABS: ✓
TRC: ×
Belts w/ tensioner: ×
Belts w/ effort limiter: ×
Belts w/ holding: ✓
Child-seat fixation: ✓
Safety planks: ✓
Brake assist: ×
Energy-absorbing body: ×
EBD: ×
Anti-theft device: ×
Additional equipment: ×

Comfort

Air conditioner: Full Auto
Power window: ✓
Central switch: ✓
Steering column length: ×
Steering column height: ✓
Cruise control: ×
Leather steering wheel: ×
Leather seats: —
Power front seat: ×
Power rear seat: ×
Wood panel: ◯
Sunroof: ×
Alloy wheels: Option settings NO
Folding seat: split
Glass w/ UV filter: ×
Toned glasses: ×

Engine

Model: EJ20
Type: horizontally-opposed 4 cylinder SOHC 16-valves
Bore x stroke, mm: 92.0x75.0
Engine size, cc: 1994
Compression ratio: 9.7
Fuel injection: EGI=電子制御燃料噴射装置(マルチポイ&#1
Max power, hp/rpm: 135ps(99kW)/5600rpm
Max torque, Nm/rpm: 18.5kg m(181.4N m)/4000rpm
Supercharger: ×
Fuel tank, liters: 60 l
Fuel: Regular unleaded gasoline
Fuel consumption, l/100km: 8.9

Steering & suspension

Steering: Power assist equipped rack&pinion
Front suspension: Strut type Independent suspension
Rear suspension: Strut type Independent suspension
Front brake: Ventilated disk
Rear brake: disk
Front wheel: 195/60R15
Rear wheel: 195/60R15
Min turn diameter, m: 5.3

Gearbox

Number of stages: 4AT
Drive: Full-time 4WD
LSD: ----

Exterior equipment

Front fog lights: ✓
Rear fog lights: ×
Xenon: ×
Extra front lights: ×
Spoilers (f / r): × / ◯
Wiper: ✓

Navigation & sound

Navigation: ×
Navigation device: It is not
Audio: AM/FM radio with CS player
CD player: ×

Gear ratios

CVT	1	2	3	4	5	6	7	Rev	Main
—	2.785	1.545	1.000	0.694	—	—	—	—	2.272

Available colors

blackwhitegreen / Other greenMaroon (brown)OliveNavy bluePurpleAshes / Other AshesYellowYellow-greenBlack (P)MagentaSilverRedBlue / Other BlueDark cyanPearlGold
