SUBARU XV HYBRID TS

SUBARU XV HYBRID

GPE · TS

Description

Modification: TS
Chassis ID: GPE
Dates releasing: 2016.7~
Base price, ¥: DAA-GPE
Body size: 4485x1780x1550
Interior (LxWxH): 2005x1490x1205
Wheelbase: 2640
Track f/r: 1535mm/1540mm
Full weight, kg: 1530
Body type: SUV
Doors / seats: 5 door / 5

Safe equipment

Driver's air bag: ✓
Front passenger air bag: ✓
Side airbags: ✓
ABS: ✓
TRC: ×
Belts w/ tensioner: ✓
Belts w/ effort limiter: ✓
Belts w/ holding: ✓
Child-seat fixation: ×
Safety planks: ✓
Brake assist: ✓
Energy-absorbing body: 採用
EBD: ✓
Anti-theft device: ✓
Additional equipment: VDC(ビークルダイナミクスコントロール)

Comfort

Air conditioner: Full Auto
Power window: ✓
Central switch: ✓
Steering column length: ✓
Steering column height: ✓
Cruise control: ✓
Leather steering wheel: ✓
Leather seats: —
Power front seat: ✓
Power rear seat: ×
Wood panel: ×
Sunroof: ×
Alloy wheels: 17 inches standard
Folding seat: split
Glass w/ UV filter: ✓
Toned glasses: ✓

Engine

Model: FB20
Type: horizontally-opposed 4 cylinder DOHC 16-valves +
Bore x stroke, mm: 84.0x90.0
Engine size, cc: 1995
Compression ratio: 10.8
Fuel injection: EGI(電子制御燃料噴射装置:マルチポイ&#1
Max power, hp/rpm: 150ps(110kW)/6000rpm
Max torque, Nm/rpm: 20.0kg m(196N m)/4200rpm
Supercharger: ×
Fuel tank, liters: 52 l
Fuel: Regular unleaded gasoline
Fuel consumption, l/100km: 4.9

Steering & suspension

Steering: Power assist equipped rack&pinion
Front suspension: Strut type Independent suspension
Rear suspension: Double wishbone type Independent suspension
Front brake: Ventilated disk
Rear brake: disk
Front wheel: 225/55R17
Rear wheel: 225/55R17
Min turn diameter, m: 5.3

Gearbox

Number of stages: CVT
Drive: Full-time 4WD
LSD: ----

Exterior equipment

Front fog lights: ✓
Rear fog lights: ✓
Xenon: ✓
Extra front lights: ×
Spoilers (f / r): ✓ / ✓
Wiper: ✓

Navigation & sound

Navigation: ×
Navigation device: It is not
Audio: It is not
CD player: ×

Gear ratios

CVT	1	2	3	4	5	6	7	Rev	Main
3.420~0.544	3.420	2.348	1.737	1.262	0.932	0.735	—	—	3.502

Available colors

black / Crystal Black SilicawhitegreenMaroon (brown)OliveNavy bluePurpleAshesYellowYellow-greenBlack (P)MagentaSilverRedBlue / Other BlueDark cyanPearl / Other PearlGold
