SUZUKI GRAND ESCUDO BASE GRADE

SUZUKI GRAND ESCUDO

TX92W · BASE GRADE

Description

Modification: BASE GRADE
Chassis ID: TX92W
Dates releasing: 2003.6~
Base price, ¥: UA-TX92W
Body size: 4640x1780x1740
Interior (LxWxH): 2395x1355x1230
Wheelbase: 2800
Track f/r: 1500mm/1500mm
Full weight, kg: 1680
Body type: SUV
Doors / seats: 5 door / 7

Safe equipment

Driver's air bag: ✓
Front passenger air bag: ✓
Side airbags: ×
ABS: ✓
TRC: ×
Belts w/ tensioner: ✓
Belts w/ effort limiter: ✓
Belts w/ holding: ✓
Child-seat fixation: ✓
Safety planks: ✓
Brake assist: ×
Energy-absorbing body: 採用
EBD: ✓
Anti-theft device: ×
Additional equipment: ×

Comfort

Air conditioner: Dual air conditioning
Power window: ✓
Central switch: ✓
Steering column length: ×
Steering column height: ✓
Cruise control: ×
Leather steering wheel: ✓
Leather seats: —
Power front seat: ×
Power rear seat: ×
Wood panel: ✓
Sunroof: ×
Alloy wheels: 16 inches standard
Folding seat: split
Glass w/ UV filter: ✓
Toned glasses: ✓

Engine

Model: H27A
Type: water cooling V-type 6 cylinder DOHC 24-valves
Bore x stroke, mm: 88.0x75.0
Engine size, cc: 2736
Compression ratio: 9.5
Fuel injection: EPI(電子制御燃料噴射装置)
Max power, hp/rpm: 184ps(135kW)/6000rpm
Max torque, Nm/rpm: 25.5kg m(250N m)/3300rpm
Supercharger: ×
Fuel tank, liters: 66 l
Fuel: Regular unleaded gasoline
Fuel consumption, l/100km: 10.6

Steering & suspension

Steering: Power assist equipped rack&pinion
Front suspension: McPherson Strut type Coil spring
Rear suspension: 5リンクリジッ DOOR クスル type Coil spring
Front brake: Ventilated disk
Rear brake: Drum
Front wheel: 235/60R16 100H
Rear wheel: 235/60R16 100H
Min turn diameter, m: 5.9

Gearbox

Number of stages: 5AT
Drive: Part-time 4WD
LSD: ----

Exterior equipment

Front fog lights: ✓
Rear fog lights: ×
Xenon: ×
Extra front lights: ×
Spoilers (f / r): × / ✓
Wiper: ✓

Navigation & sound

Navigation: ×
Navigation device: It is not
Audio: It is not
CD player: ×

Gear ratios

CVT	1	2	3	4	5	6	7	Rev	Main
—	3.520	2.043	1.401	1.000	0.717	—	—	—	3.224

Available colors

blackwhitegreenMaroon (brown)OliveNavy bluePurpleAshesYellowYellow-greenBlack (P)MagentaSilver / Silver metallicRedBlue / Other BlueDark cyanPearl / Other PearlGold / Other Gold
