SUZUKI JIMNY SIERRA BASEGRADE

SUZUKI JIMNY SIERRA

JB31W · BASEGRADE

Description

Modification: BASEGRADE
Chassis ID: JB31W
Dates releasing: 1993.5~
Base price, ¥: E-JB31W
Body size: 3470x1545x1670
Interior (LxWxH): 1675x1215x1160
Wheelbase: 2030
Track f/r: 1300mm/1310mm
Full weight, kg: 970
Body type: SUV
Doors / seats: 3 door / 4

Safe equipment

Driver's air bag: ×
Front passenger air bag: ×
Side airbags: ×
ABS: ×
TRC: ×
Belts w/ tensioner: ×
Belts w/ effort limiter: ×
Belts w/ holding: ✓
Child-seat fixation: ×
Safety planks: ✓
Brake assist: ×
Energy-absorbing body: ×
EBD: ×
Anti-theft device: ×
Additional equipment: ×

Comfort

Air conditioner: ×
Power window: ×
Central switch: ×
Steering column length: ×
Steering column height: ×
Cruise control: ×
Leather steering wheel: ×
Leather seats: —
Power front seat: ×
Power rear seat: ×
Wood panel: ×
Sunroof: ×
Alloy wheels: Option settings NO
Folding seat: split
Glass w/ UV filter: ×
Toned glasses: ×

Engine

Model: G13B
Type: water cooling inline 4 cylinder SOHC
Bore x stroke, mm: 74.0x75.5
Engine size, cc: 1298
Compression ratio: 9.5
Fuel injection: EPI(電子制御燃料噴射)
Max power, hp/rpm: 70ps(51kW)/6000rpm
Max torque, Nm/rpm: 10.4kg m(102.0N m)/3500rpm
Supercharger: ×
Fuel tank, liters: 40 l
Fuel: Regular unleaded gasoline
Fuel consumption, l/100km: 7.7

Steering & suspension

Steering: Other
Front suspension: リジッ DOOR クスル type 半楕円リーフスプ&#12
Rear suspension: リジッ DOOR クスル type 半楕円リーフスプ&#12
Front brake: disk
Rear brake: Drum
Front wheel: 205/70R15 95Q
Rear wheel: 205/70R15 95Q
Min turn diameter, m: 5.1

Gearbox

Number of stages: 5MT
Drive: Part-time 4WD
LSD: ◯

Exterior equipment

Front fog lights: ✓
Rear fog lights: ×
Xenon: ×
Extra front lights: ×
Spoilers (f / r): × / ×
Wiper: ×

Navigation & sound

Navigation: ×
Navigation device: It is not
Audio: AM/FM radio with CS player
CD player: ×

Gear ratios

CVT	1	2	3	4	5	6	7	Rev	Main
—	3.652	1.947	1.423	1.000	0.795	—	—	—	3.466

Available colors

blackwhitegreenMaroon (brown)OliveNavy blue / Other Navy bluePurpleAshesYellowYellow-greenBlack (P)MagentaSilverRed / Other RedBlueDark cyanPearlGold
