TOYOTA AQUA CROSSOVER

TOYOTA AQUA

NHP10H · CROSSOVER

Description

Modification: CROSSOVER
Chassis ID: NHP10H
Dates releasing: 2017.7~
Base price, ¥: DAA-NHP10H
Body size: 4060x1715x1500
Interior (LxWxH): 2015x1395x1175
Wheelbase: 2550
Track f/r: 1465mm/1460mm
Full weight, kg: 1100
Body type: Hatch
Doors / seats: 5 door / 5

Safe equipment

Driver's air bag: ✓
Front passenger air bag: ✓
Side airbags: ◯
ABS: ✓
TRC: ✓
Belts w/ tensioner: ✓
Belts w/ effort limiter: ✓
Belts w/ holding: ✓
Child-seat fixation: ×
Safety planks: ✓
Brake assist: ✓
Energy-absorbing body: 採用
EBD: ✓
Anti-theft device: ✓
Additional equipment: VSC

Comfort

Air conditioner: Full Auto
Power window: ✓
Central switch: ✓
Steering column length: ✓
Steering column height: ✓
Cruise control: ×
Leather steering wheel: ×
Leather seats: —
Power front seat: ×
Power rear seat: ×
Wood panel: ×
Sunroof: ×
Alloy wheels: 16 inches standard
Folding seat: split
Glass w/ UV filter: ✓
Toned glasses: ✓

Engine

Model: 1NZ-FXE
Type: inline 4 cylinder +
Bore x stroke, mm: 75.0x84.7
Engine size, cc: 1496
Compression ratio: ----
Fuel injection: 電子制御 type 燃料噴射装置(EFI)
Max power, hp/rpm: 74ps(54kW)/4800rpm
Max torque, Nm/rpm: 11.3kg m(111N m)/3600~4400rpm
Supercharger: ×
Fuel tank, liters: 36 l
Fuel: Regular unleaded gasoline
Fuel consumption, l/100km: 2.9

Steering & suspension

Steering: Power assist equipped rack&pinion
Front suspension: Strut type Coil spring (stabilizer attaching)
Rear suspension: Torsion beam
Front brake: Ventilated disk
Rear brake: Drum
Front wheel: 185/60R16
Rear wheel: 185/60R16
Min turn diameter, m: 5.4

Gearbox

Number of stages: CVT
Drive: FF
LSD: ----

Exterior equipment

Front fog lights: ×
Rear fog lights: ◯
Xenon: ×
Extra front lights: ✓
Spoilers (f / r): ✓ / ✓
Wiper: ✓

Navigation & sound

Navigation: ×
Navigation device: It is not
Audio: It is not
CD player: ×

Gear ratios

CVT	1	2	3	4	5	6	7	Rev	Main
—	—	—	—	—	—	—	—	—	----

Available colors

black / black micawhite / Super White IIgreenMaroon (brown)OliveNavy bluePurple / Other PurpleAshes / Gray metallicYellow / Other YellowYellow-green / Other Yellow-greenBlack (P) / Other Black (P)MagentaSilverRed / Super Red VBlue / Other BlueDark cyan / Other Dark cyanPearl / Other PearlGold / Other Gold
