JDM Vehicle Catalog

Vehicle Specs

TOYOTA CAMRY ZV

TOYOTA CAMRY

CV30 · ZV

Description

Modification: ZV
Chassis ID: CV30
Dates releasing: 1990.7~
Base price, ¥: X-CV30
Body size: 4600x1695x1395
Interior (LxWxH): 1925x1440x1165
Wheelbase: 2600
Track f/r: 1480mm/1440mm
Full weight, kg: 1250
Body type: Sedan
Doors / seats: 4 door / 5

Safe equipment

Driver's air bag: ◯
Front passenger air bag: ×
Side airbags: ×
ABS: ×
TRC: ×
Belts w/ tensioner: ×
Belts w/ effort limiter: ×
Belts w/ holding: ✓
Child-seat fixation: ×
Safety planks: ×
Brake assist: ×
Energy-absorbing body: ×
EBD: ×
Anti-theft device: ×
Additional equipment: ×

Comfort

Air conditioner: ×
Power window: ◯
Central switch: ◯
Steering column length: ×
Steering column height: ✓
Cruise control: ×
Leather steering wheel: ◯
Leather seats: —
Power front seat: ×
Power rear seat: ×
Wood panel: ×
Sunroof: ×
Alloy wheels: Option settings YES
Folding seat: ×
Glass w/ UV filter: ×
Toned glasses: ×

Engine

Model: 2C-T
Type: inline 4 cylinder OHCIC-turbo (Diesel)
Bore x stroke, mm: 86.0x85.0
Engine size, cc: 1974
Compression ratio: 23.0
Fuel injection: ボッシュ type 分配型噴射ポンプ
Max power, hp/rpm: 91ps(67kW)/4400rpm
Max torque, Nm/rpm: 19.4kg m(190N m)/2600rpm
Supercharger: IC turbo
Fuel tank, liters: 60 l
Fuel: Diesel
Fuel consumption, l/100km: 0

Steering & suspension

Steering: Power assist equipped rack&pinion
Front suspension: Strut type Coil spring
Rear suspension: Strut type Coil spring
Front brake: Ventilated disk
Rear brake: Drum
Front wheel: 185/70R14 87S
Rear wheel: 185/70R14 87S
Min turn diameter, m: 5.3

Gearbox

Number of stages: 4AT
Drive: FF
LSD: ----

Exterior equipment

Front fog lights: ✓
Rear fog lights: ×
Xenon: ×
Extra front lights: ×
Spoilers (f / r): × / ×
Wiper: ×

Navigation & sound

Navigation: ×
Navigation device: It is not
Audio: AM/FMラジオ
CD player: ×

Gear ratios

CVT	1	2	3	4	5	6	7	Rev	Main
—	2.810	1.549	1.000	0.706	—	—	—	—	2.296

Available colors

blackwhite / Super White IIgreenMaroon (brown)OliveNavy blue / Other Navy bluePurple / Other PurpleAshesYellowYellow-greenBlack (P)MagentaSilverRed / Red mica metallicBlueDark cyan / Other Dark cyanPearlGold
