TOYOTA CARINA MY ROAD-I

TOYOTA CARINA

AT190 · MY ROAD-I

Description

Modification: MY ROAD-I
Chassis ID: AT190
Dates releasing: 1994.1~
Base price, ¥: E-AT190
Body size: 4455x1695x1395
Interior (LxWxH): 1955x1445x1165
Wheelbase: 2580
Track f/r: 1465mm/1450mm
Full weight, kg: 1110
Body type: Sedan
Doors / seats: 4 door / 5

Safe equipment

Driver's air bag: ◯
Front passenger air bag: ×
Side airbags: ×
ABS: ×
TRC: ×
Belts w/ tensioner: ×
Belts w/ effort limiter: ×
Belts w/ holding: ✓
Child-seat fixation: ×
Safety planks: ✓
Brake assist: ×
Energy-absorbing body: ×
EBD: ×
Anti-theft device: ×
Additional equipment: ×

Comfort

Air conditioner: Full Auto
Power window: ✓
Central switch: ✓
Steering column length: ×
Steering column height: ✓
Cruise control: ×
Leather steering wheel: ×
Leather seats: —
Power front seat: ×
Power rear seat: ×
Wood panel: ×
Sunroof: ◯
Alloy wheels: Option settings YES
Folding seat: split
Glass w/ UV filter: ×
Toned glasses: ×

Engine

Model: 4A-FE
Type: inline 4 cylinder DOHC 16-valves
Bore x stroke, mm: 81.0x77.0
Engine size, cc: 1587
Compression ratio: 9.5
Fuel injection: EFI(電子制御燃料噴射装置)
Max power, hp/rpm: 105ps(77kW)/6000rpm
Max torque, Nm/rpm: 14.2kg m(139.3N m)/4800rpm
Supercharger: ×
Fuel tank, liters: 55 l
Fuel: Regular unleaded gasoline
Fuel consumption, l/100km: 7.3

Steering & suspension

Steering: Power assist equipped rack&pinion
Front suspension: Strut type Coil spring (stabilizer attaching)
Rear suspension: Strut type Coil spring
Front brake: Ventilated disk
Rear brake: Drum
Front wheel: 175/70R14 84S
Rear wheel: 175/70R14 84S
Min turn diameter, m: 5.1

Gearbox

Number of stages: 4AT
Drive: FF
LSD: ----

Exterior equipment

Front fog lights: ✓
Rear fog lights: ×
Xenon: ×
Extra front lights: ×
Spoilers (f / r): × / ◯
Wiper: ◯

Navigation & sound

Navigation: ×
Navigation device: It is not
Audio: AM/FMラジオ
CD player: ×

Gear ratios

CVT	1	2	3	4	5	6	7	Rev	Main
—	—	—	—	—	—	—	—	—	----

Available colors

blackwhite / Super White IIgreenMaroon (brown)OliveNavy bluePurpleAshes / Dark bluish gray metallicYellowYellow-greenBlack (P)MagentaSilverRed / Other RedBlueDark cyanPearlGold / Other Gold
