TOYOTA CARINA S

TOYOTA CARINA

AT171 · S

Description

Modification: S
Chassis ID: AT171
Dates releasing: 1990.5~
Base price, ¥: E-AT171
Body size: 4420x1690x1370
Interior (LxWxH): 1875x1420x1150
Wheelbase: 2525
Track f/r: 1470mm/1440mm
Full weight, kg: 1060
Body type: Sedan
Doors / seats: 4 door / 5

Safe equipment

Driver's air bag: ×
Front passenger air bag: ×
Side airbags: ×
ABS: ◯
TRC: ×
Belts w/ tensioner: ×
Belts w/ effort limiter: ×
Belts w/ holding: ×
Child-seat fixation: ×
Safety planks: ×
Brake assist: ×
Energy-absorbing body: ×
EBD: ×
Anti-theft device: ×
Additional equipment: ×

Comfort

Air conditioner: ×
Power window: ◯
Central switch: ◯
Steering column length: ×
Steering column height: ✓
Cruise control: ×
Leather steering wheel: ×
Leather seats: —
Power front seat: ×
Power rear seat: ×
Wood panel: ×
Sunroof: ◯
Alloy wheels: Option settings YES
Folding seat: ×
Glass w/ UV filter: ×
Toned glasses: ×

Engine

Model: 4A-FHE
Type: inline 4 cylinder DOHC 16-valves
Bore x stroke, mm: 81.0x77.0
Engine size, cc: 1587
Compression ratio: 9.5
Fuel injection: EFI
Max power, hp/rpm: 110ps(81kW)/6000rpm
Max torque, Nm/rpm: 14.5kg m(142.2N m)/4800rpm
Supercharger: ×
Fuel tank, liters: 60 l
Fuel: Regular unleaded gasoline
Fuel consumption, l/100km: 7.7

Steering & suspension

Steering: Power assist equipped rack&pinion
Front suspension: Strut type Coil spring /スタビライザー付
Rear suspension: Strut type Coil spring /スタビライザー付
Front brake: Ventilated disk
Rear brake: Drum
Front wheel: 185/65R14 85S
Rear wheel: 185/65R14 85S
Min turn diameter, m: 5.2

Gearbox

Number of stages: 5MT
Drive: FF
LSD: ----

Exterior equipment

Front fog lights: ×
Rear fog lights: ×
Xenon: ×
Extra front lights: ×
Spoilers (f / r): ✓ / ◯
Wiper: ×

Navigation & sound

Navigation: ×
Navigation device: It is not
Audio: AM/FMラジオ
CD player: ×

Gear ratios

CVT	1	2	3	4	5	6	7	Rev	Main
—	3.545	1.904	1.233	0.885	0.725	—	—	—	3.250

Available colors

blackwhite / Super White IIgreenMaroon (brown)OliveNavy blue / Dark blue mica metallicPurpleAshes / Other AshesYellowYellow-greenBlack (P) / Other Black (P)MagentaSilver / Other SilverRed / Red micaBlueDark cyan / Other Dark cyanPearlGold
