TOYOTA CARINA TURBO TI MY ROAD

TOYOTA CARINA

CT216 · TURBO TI MY ROAD

Description

Modification: TURBO TI MY ROAD
Chassis ID: CT216
Dates releasing: 1998.8~
Base price, ¥: KH-CT216
Body size: 4495x1695x1420
Interior (LxWxH): 1940x1415x1160
Wheelbase: 2580
Track f/r: 1465mm/1435mm
Full weight, kg: 1310
Body type: Sedan
Doors / seats: 4 door / 5

Safe equipment

Driver's air bag: ✓
Front passenger air bag: ✓
Side airbags: ×
ABS: ✓
TRC: ×
Belts w/ tensioner: ✓
Belts w/ effort limiter: ✓
Belts w/ holding: ✓
Child-seat fixation: ✓
Safety planks: ✓
Brake assist: ×
Energy-absorbing body: ×
EBD: ×
Anti-theft device: ×
Additional equipment: ×

Comfort

Air conditioner: Full Auto
Power window: ✓
Central switch: ✓
Steering column length: ×
Steering column height: ✓
Cruise control: ×
Leather steering wheel: ×
Leather seats: —
Power front seat: ×
Power rear seat: ×
Wood panel: ◯
Sunroof: ×
Alloy wheels: Option settings NO
Folding seat: 一体
Glass w/ UV filter: ✓
Toned glasses: ×

Engine

Model: 3C-TE
Type: inline 4 cylinder OHCturbo (Diesel)
Bore x stroke, mm: 86.0x94.0
Engine size, cc: 2184
Compression ratio: 22.6
Fuel injection: 電子制御 type 分配型燃料噴射装置
Max power, hp/rpm: 94ps(69kW)/4000rpm
Max torque, Nm/rpm: 21.0kg m(205.9N m)/2200rpm
Supercharger: Turbo
Fuel tank, liters: 60 l
Fuel: Diesel
Fuel consumption, l/100km: 0

Steering & suspension

Steering: Power assist equipped rack&pinion
Front suspension: Strut type Coil spring (stabilizer attaching)
Rear suspension: Strut type Coil spring (stabilizer attaching)
Front brake: Ventilated disk
Rear brake: Drum
Front wheel: 185/65R14 86S
Rear wheel: 185/65R14 86S
Min turn diameter, m: 5.5

Gearbox

Number of stages: 4AT
Drive: Full-time 4WD
LSD: ----

Exterior equipment

Front fog lights: ✓
Rear fog lights: ×
Xenon: ×
Extra front lights: ×
Spoilers (f / r): × / ◯
Wiper: ◯

Navigation & sound

Navigation: ◯
Navigation device: It is not
Audio: It is not
CD player: ×

Gear ratios

CVT	1	2	3	4	5	6	7	Rev	Main
—	—	—	—	—	—	—	—	—	----

Available colors

blackwhite / Super White IIgreenMaroon (brown)OliveNavy bluePurple / Other PurpleAshesYellowYellow-green / Light green metallicBlack (P)MagentaSilverRed / Red micaBlue / Dark blue mica metallicDark cyanPearlGold
