TOYOTA CELICA SS-I

TOYOTA CELICA

ZZT230 · SS-I

Description

Modification: SS-I
Chassis ID: ZZT230
Dates releasing: 1999.9~
Base price, ¥: GH-ZZT230
Body size: 4335x1735x1305
Interior (LxWxH): 1725x1440x1085
Wheelbase: 2600
Track f/r: 1490mm/1480mm
Full weight, kg: 1090
Body type: Coupe
Doors / seats: 3 door / 4

Safe equipment

Driver's air bag: ✓
Front passenger air bag: ✓
Side airbags: ◯
ABS: ✓
TRC: ×
Belts w/ tensioner: ✓
Belts w/ effort limiter: ✓
Belts w/ holding: ✓
Child-seat fixation: ✓
Safety planks: ✓
Brake assist: ×
Energy-absorbing body: ×
EBD: ×
Anti-theft device: ×
Additional equipment: ×

Comfort

Air conditioner: Manual
Power window: ✓
Central switch: ✓
Steering column length: ×
Steering column height: ✓
Cruise control: ×
Leather steering wheel: ×
Leather seats: —
Power front seat: ×
Power rear seat: ×
Wood panel: ×
Sunroof: ◯
Alloy wheels: Option settings YES
Folding seat: split
Glass w/ UV filter: ✓
Toned glasses: ×

Engine

Model: 1ZZ-FE
Type: inline 4 cylinder DOHC 16-valves
Bore x stroke, mm: 79.0x91.5
Engine size, cc: 1794
Compression ratio: 10.0
Fuel injection: EFI
Max power, hp/rpm: 145ps(107kW)/6400rpm
Max torque, Nm/rpm: 17.4kg m(170.6N m)/4200rpm
Supercharger: ×
Fuel tank, liters: 55 l
Fuel: Regular unleaded gasoline
Fuel consumption, l/100km: 7.1

Steering & suspension

Steering: Power assist equipped rack&pinion
Front suspension: Strut type Coil spring
Rear suspension: Double wishbone type Coil spring
Front brake: Ventilated disk
Rear brake: Drum
Front wheel: 195/60R15 88H
Rear wheel: 195/60R15 88H
Min turn diameter, m: 5.2

Gearbox

Number of stages: 5MT
Drive: FF
LSD: ----

Exterior equipment

Front fog lights: ◯
Rear fog lights: ◯
Xenon: ×
Extra front lights: ✓
Spoilers (f / r): ✓ / ◯
Wiper: ✓

Navigation & sound

Navigation: ◯
Navigation device: It is not
Audio: It is not
CD player: ×

Gear ratios

CVT	1	2	3	4	5	6	7	Rev	Main
—	3.166	1.904	1.392	1.031	0.815	—	—	—	3.250

Available colors

black / Other blackwhite / Super White IIgreenMaroon (brown)OliveNavy bluePurpleAshesYellow / Other YellowYellow-greenBlack (P)MagentaSilverRed / Super Red VBlueDark cyanPearlGold
