TOYOTA COROLLA FIELDER S 40TH ANNIVERSARY LIMITED

TOYOTA COROLLA FIELDER

ZZE124G · S 40TH ANNIVERSARY LIMITED

Description

Modification: S 40TH ANNIVERSARY LIMITED
Chassis ID: ZZE124G
Dates releasing: 2005.12~
Base price, ¥: CBA-ZZE124G
Body size: 4410x1695x1530
Interior (LxWxH): 1910x1430x1230
Wheelbase: 2600
Track f/r: 1480mm/1460mm
Full weight, kg: 1250
Body type: Wagon
Doors / seats: 5 door / 5

Safe equipment

Driver's air bag: ✓
Front passenger air bag: ✓
Side airbags: ◯
ABS: ✓
TRC: ×
Belts w/ tensioner: ✓
Belts w/ effort limiter: ✓
Belts w/ holding: ✓
Child-seat fixation: ✓
Safety planks: ✓
Brake assist: ✓
Energy-absorbing body: 採用
EBD: ✓
Anti-theft device: ✓
Additional equipment: ×

Comfort

Air conditioner: Full Auto
Power window: ✓
Central switch: ✓
Steering column length: ×
Steering column height: ✓
Cruise control: ×
Leather steering wheel: ✓
Leather seats: —
Power front seat: ×
Power rear seat: ×
Wood panel: ×
Sunroof: ◯
Alloy wheels: 15 inches standard
Folding seat: split
Glass w/ UV filter: ✓
Toned glasses: ✓

Engine

Model: 1ZZ-FE
Type: inline 4 cylinder DOHC 16-valves
Bore x stroke, mm: 79.0x91.5
Engine size, cc: 1794
Compression ratio: 10.0
Fuel injection: EFI[電子制御 type 燃料噴射装置]
Max power, hp/rpm: 125ps(92kW)/6000rpm
Max torque, Nm/rpm: 16.4kg m(161N m)/4200rpm
Supercharger: ×
Fuel tank, liters: 50 l
Fuel: Regular unleaded gasoline
Fuel consumption, l/100km: 7.2

Steering & suspension

Steering: Power assist equipped rack&pinion
Front suspension: Strut type Coil spring
Rear suspension: Double wishbone type Coil spring
Front brake: Ventilated disk
Rear brake: Drum
Front wheel: 195/60R15 88V
Rear wheel: 195/60R15 88V
Min turn diameter, m: 5.2

Gearbox

Number of stages: 4AT
Drive: Full-time 4WD
LSD: ----

Exterior equipment

Front fog lights: ×
Rear fog lights: ◯
Xenon: ✓
Extra front lights: ×
Spoilers (f / r): ✓ / ✓
Wiper: ✓

Navigation & sound

Navigation: ◯
Navigation device: DVD
Audio: It is not
CD player: ×

Gear ratios

CVT	1	2	3	4	5	6	7	Rev	Main
—	2.847	1.552	1.000	0.700	—	—	—	—	2.343

Available colors

black / black micawhite / Super White IIgreenMaroon (brown)OliveNavy bluePurpleAshesYellowYellow-greenBlack (P)MagentaSilver / Silver metallicRed / Super Red IIBlueDark cyanPearl / White Pearl Crystal ShineGold
