TOYOTA COROLLA RUNX Z AERO TOURER

TOYOTA COROLLA RUNX

ZZE123 · Z AERO TOURER

Description

Modification: Z AERO TOURER
Chassis ID: ZZE123
Dates releasing: 2001.12~
Base price, ¥: TA-ZZE123
Body size: 4175x1695x1470
Interior (LxWxH): 1900x1430x1230
Wheelbase: 2600
Track f/r: 1480mm/1460mm
Full weight, kg: 1190
Body type: Hatch
Doors / seats: 5 door / 5

Safe equipment

Driver's air bag: ✓
Front passenger air bag: ✓
Side airbags: ×
ABS: ✓
TRC: ×
Belts w/ tensioner: ✓
Belts w/ effort limiter: ✓
Belts w/ holding: ✓
Child-seat fixation: ✓
Safety planks: ✓
Brake assist: ✓
Energy-absorbing body: 採用
EBD: ✓
Anti-theft device: ◯
Additional equipment: ×

Comfort

Air conditioner: Full Auto
Power window: ✓
Central switch: ✓
Steering column length: ×
Steering column height: ✓
Cruise control: ×
Leather steering wheel: ✓
Leather seats: —
Power front seat: ×
Power rear seat: ×
Wood panel: ◯
Sunroof: ◯
Alloy wheels: Option settings YES
Folding seat: split
Glass w/ UV filter: ✓
Toned glasses: ✓

Engine

Model: 2ZZ-GE
Type: inline 4 cylinder DOHC 16-valves
Bore x stroke, mm: 82.0x85.0
Engine size, cc: 1795
Compression ratio: 11.5
Fuel injection: EFI
Max power, hp/rpm: 190ps(140kW)/7600rpm
Max torque, Nm/rpm: 18.4kg m(180N m)/6800rpm
Supercharger: ×
Fuel tank, liters: 50 l
Fuel: Unleaded premium gasoline
Fuel consumption, l/100km: 8.3

Steering & suspension

Steering: Power assist equipped rack&pinion
Front suspension: Strut type Coil spring
Rear suspension: Torsion beam
Front brake: Ventilated disk
Rear brake: disk
Front wheel: 195/60R15 88V
Rear wheel: 195/60R15 88V
Min turn diameter, m: 5.1

Gearbox

Number of stages: 4AT
Drive: FF
LSD: ----

Exterior equipment

Front fog lights: ✓
Rear fog lights: ◯
Xenon: ×
Extra front lights: ×
Spoilers (f / r): ✓ / ✓
Wiper: ✓

Navigation & sound

Navigation: ◯
Navigation device: DVD
Audio: It is not
CD player: ×

Gear ratios

CVT	1	2	3	4	5	6	7	Rev	Main
—	3.943	2.197	1.413	1.020	—	—	—	—	3.145

Available colors

black / black micawhite / Super White IIgreenMaroon (brown)OliveNavy blue / Dark blue mica metallicPurpleAshesYellowYellow-greenBlack (P)MagentaSilverRed / Super Red IIBlueDark cyanPearlGold / Beige Metallic
