TOYOTA CORONA EXIV FE

TOYOTA CORONA EXIV

ST181 · FE

Description

Modification: FE
Chassis ID: ST181
Dates releasing: 1991.8~
Base price, ¥: E-ST181
Body size: 4505x1690x1320
Interior (LxWxH): 1755x1405x1090
Wheelbase: 2525
Track f/r: 1465mm/1430mm
Full weight, kg: 1250
Body type: Hardtop
Doors / seats: 4 door / 5

Safe equipment

Driver's air bag: ◯
Front passenger air bag: ×
Side airbags: ×
ABS: ◯
TRC: ×
Belts w/ tensioner: ×
Belts w/ effort limiter: ×
Belts w/ holding: ✓
Child-seat fixation: ×
Safety planks: ✓
Brake assist: ×
Energy-absorbing body: ×
EBD: ×
Anti-theft device: ×
Additional equipment: ×

Comfort

Air conditioner: Full Auto
Power window: ✓
Central switch: ✓
Steering column length: ✓
Steering column height: ✓
Cruise control: ×
Leather steering wheel: ×
Leather seats: —
Power front seat: ×
Power rear seat: ×
Wood panel: ×
Sunroof: ◯
Alloy wheels: Option settings YES
Folding seat: split
Glass w/ UV filter: ×
Toned glasses: ×

Engine

Model: 4S-FE
Type: inline 4 cylinder DOHC 16-valves
Bore x stroke, mm: 82.5x86.0
Engine size, cc: 1838
Compression ratio: 9.3
Fuel injection: EFI
Max power, hp/rpm: 115ps(85kW)/5600rpm
Max torque, Nm/rpm: 16.0kg m(156.9N m)/4400rpm
Supercharger: ×
Fuel tank, liters: 60 l
Fuel: Regular unleaded gasoline
Fuel consumption, l/100km: 8.6

Steering & suspension

Steering: Power assist equipped rack&pinion
Front suspension: Strut type Coil spring (stabilizer attaching)
Rear suspension: Strut type Coil spring (stabilizer attaching)
Front brake: Ventilated disk
Rear brake: Drum
Front wheel: 185/65R14 85S
Rear wheel: 185/65R14 85S
Min turn diameter, m: 4.7

Gearbox

Number of stages: 4AT
Drive: FF
LSD: ----

Exterior equipment

Front fog lights: ✓
Rear fog lights: ×
Xenon: ×
Extra front lights: ×
Spoilers (f / r): × / ◯
Wiper: ◯

Navigation & sound

Navigation: ×
Navigation device: It is not
Audio: AM/FM radio with CS player
CD player: ×

Gear ratios

CVT	1	2	3	4	5	6	7	Rev	Main
—	2.810	1.549	1.000	0.706	—	—	—	—	2.296

Available colors

black / Other blackwhite / Super White IIgreen / Other greenMaroon (brown) / Other Maroon (brown)OliveNavy bluePurpleAshes / Bluish gray metallicYellowYellow-greenBlack (P)MagentaSilverRedBlue / Other BlueDark cyanPearlGold
