TOYOTA CORONA EXIV TR-R

TOYOTA CORONA EXIV

ST203 · TR-R

Description

Modification: TR-R
Chassis ID: ST203
Dates releasing: 1993.10~
Base price, ¥: E-ST203
Body size: 4500x1740x1325
Interior (LxWxH): 1805x1415x1110
Wheelbase: 2535
Track f/r: 1510mm/1480mm
Full weight, kg: 1180
Body type: Hardtop
Doors / seats: 4 door / 5

Safe equipment

Driver's air bag: ◯
Front passenger air bag: ×
Side airbags: ×
ABS: ◯
TRC: ×
Belts w/ tensioner: ×
Belts w/ effort limiter: ×
Belts w/ holding: ✓
Child-seat fixation: ×
Safety planks: ✓
Brake assist: ×
Energy-absorbing body: ×
EBD: ×
Anti-theft device: ×
Additional equipment: ×

Comfort

Air conditioner: Full Auto
Power window: ✓
Central switch: ✓
Steering column length: ×
Steering column height: ✓
Cruise control: ×
Leather steering wheel: ✓
Leather seats: —
Power front seat: ×
Power rear seat: ×
Wood panel: ◯
Sunroof: ◯
Alloy wheels: Option settings YES
Folding seat: split
Glass w/ UV filter: ×
Toned glasses: ×

Engine

Model: 3S-FE
Type: water cooling inline 4 cylinder DOHC 16-valves
Bore x stroke, mm: 86.0x86.0
Engine size, cc: 1998
Compression ratio: 9.5
Fuel injection: EFI
Max power, hp/rpm: 140ps(103kW)/6000rpm
Max torque, Nm/rpm: 19.0kg m(186.3N m)/4400rpm
Supercharger: ×
Fuel tank, liters: 60 l
Fuel: Regular unleaded gasoline
Fuel consumption, l/100km: 7.3

Steering & suspension

Steering: Power assist equipped rack&pinion
Front suspension: Strut type Coil spring (stabilizer attaching)
Rear suspension: Strut type Coil spring (stabilizer attaching)
Front brake: Ventilated disk
Rear brake: disk
Front wheel: 195/65R14 89S
Rear wheel: 195/65R14 89S
Min turn diameter, m: 4.7

Gearbox

Number of stages: 5MT
Drive: FF
LSD: ----

Exterior equipment

Front fog lights: ✓
Rear fog lights: ×
Xenon: ×
Extra front lights: ×
Spoilers (f / r): × / ◯
Wiper: ◯

Navigation & sound

Navigation: ×
Navigation device: It is not
Audio: It is not
CD player: ×

Gear ratios

CVT	1	2	3	4	5	6	7	Rev	Main
—	3.285	1.960	1.322	1.028	0.820	—	—	—	3.153

Available colors

blackwhite / Super White IIgreen / Dark green micaMaroon (brown)Olive / Other OliveNavy bluePurpleAshesYellowYellow-greenBlack (P)MagentaSilverRed / Red mica metallicBlueDark cyanPearl / Other PearlGold
