TOYOTA CORSA AX-X

TOYOTA CORSA

EL51 · AX-X

Description

Modification: AX-X
Chassis ID: EL51
Dates releasing: 1997.12~
Base price, ¥: E-EL51
Body size: 4130x1660x1370
Interior (LxWxH): 1750x1370x1160
Wheelbase: 2380
Track f/r: 1400mm/1430mm
Full weight, kg: 950
Body type: Sedan
Doors / seats: 4 door / 5

Safe equipment

Driver's air bag: ✓
Front passenger air bag: ✓
Side airbags: ×
ABS: ✓
TRC: ×
Belts w/ tensioner: ✓
Belts w/ effort limiter: ✓
Belts w/ holding: ✓
Child-seat fixation: ✓
Safety planks: ✓
Brake assist: ✓
Energy-absorbing body: 採用
EBD: ×
Anti-theft device: ◯
Additional equipment: ×

Comfort

Air conditioner: Manual
Power window: ✓
Central switch: ✓
Steering column length: ×
Steering column height: ✓
Cruise control: ×
Leather steering wheel: ×
Leather seats: —
Power front seat: ×
Power rear seat: ×
Wood panel: ◯
Sunroof: ×
Alloy wheels: Option settings NO
Folding seat: ×
Glass w/ UV filter: ✓
Toned glasses: ×

Engine

Model: 4E-FE
Type: water cooling inline 4 cylinder DOHC 16-valves
Bore x stroke, mm: 74.0x77.4
Engine size, cc: 1331
Compression ratio: 9.6
Fuel injection: EFI-D<電子制御 type 燃料噴射装置>
Max power, hp/rpm: 85ps(63kW)/5500rpm
Max torque, Nm/rpm: 12.0kg m(117.7N m)/4400rpm
Supercharger: ×
Fuel tank, liters: 45 l
Fuel: Regular unleaded gasoline
Fuel consumption, l/100km: 6.2

Steering & suspension

Steering: Power assist equipped rack&pinion
Front suspension: Strut type Coil spring
Rear suspension: トレーリングツイストビーム type Coil spring (stabi
Front brake: Ventilated disk
Rear brake: Drum
Front wheel: 155/80R13 79S
Rear wheel: 155/80R13 79S
Min turn diameter, m: 4.5

Gearbox

Number of stages: 3AT
Drive: FF
LSD: ----

Exterior equipment

Front fog lights: ◯
Rear fog lights: ×
Xenon: ×
Extra front lights: ×
Spoilers (f / r): × / ×
Wiper: ×

Navigation & sound

Navigation: ◯
Navigation device: It is not
Audio: It is not
CD player: ×

Gear ratios

CVT	1	2	3	4	5	6	7	Rev	Main
—	2.810	1.549	1.000	—	—	—	—	—	2.296

Available colors

blackwhite / Super White IIgreen / Dark green mica metallicMaroon (brown)OliveNavy blue / Dark blue mica metallicPurpleAshesYellowYellow-greenBlack (P)MagentaSilver / Other SilverRedBlue / Blue mica metallicDark cyan / Other Dark cyanPearlGold
