JDM Vehicle Catalog

Vehicle Specs

TOYOTA CORSA CYNTHIA

TOYOTA CORSA

EL53 · CYNTHIA

Description

Modification: CYNTHIA
Chassis ID: EL53
Dates releasing: 1997.12~
Base price, ¥: E-EL53
Body size: 3915x1660x1370
Interior (LxWxH): 1750x1380x1160
Wheelbase: 2380
Track f/r: 1400mm/1395mm
Full weight, kg: 920
Body type: Hatch
Doors / seats: 3 door / 5

Safe equipment

Driver's air bag: ✓
Front passenger air bag: ✓
Side airbags: ×
ABS: ✓
TRC: ×
Belts w/ tensioner: ✓
Belts w/ effort limiter: ✓
Belts w/ holding: ✓
Child-seat fixation: ✓
Safety planks: ✓
Brake assist: ✓
Energy-absorbing body: 採用
EBD: ×
Anti-theft device: ◯
Additional equipment: ×

Comfort

Air conditioner: Manual
Power window: ✓
Central switch: ✓
Steering column length: ×
Steering column height: ✓
Cruise control: ×
Leather steering wheel: ×
Leather seats: —
Power front seat: ×
Power rear seat: ×
Wood panel: ◯
Sunroof: ◯
Alloy wheels: Option settings YES
Folding seat: 一体
Glass w/ UV filter: ✓
Toned glasses: ×

Engine

Model: 5E-FE
Type: water cooling inline 4 cylinder DOHC 16-valves
Bore x stroke, mm: 74.0x87.0
Engine size, cc: 1496
Compression ratio: 9.8
Fuel injection: EFI-D<電子制御 type 燃料噴射装置>
Max power, hp/rpm: 94ps(69kW)/5400rpm
Max torque, Nm/rpm: 13.5kg m(132.4N m)/4400rpm
Supercharger: ×
Fuel tank, liters: 45 l
Fuel: Regular unleaded gasoline
Fuel consumption, l/100km: 5.2

Steering & suspension

Steering: Power assist equipped rack&pinion
Front suspension: Strut type Coil spring (stabilizer attaching)
Rear suspension: トレーリングツイストビーム type Coil spring (stabi
Front brake: Ventilated disk
Rear brake: Drum
Front wheel: 175/70R13 82S
Rear wheel: 175/70R13 82S
Min turn diameter, m: 4.8

Gearbox

Number of stages: 5MT
Drive: FF
LSD: ----

Exterior equipment

Front fog lights: ◯
Rear fog lights: ×
Xenon: ×
Extra front lights: ×
Spoilers (f / r): × / ◯
Wiper: ✓

Navigation & sound

Navigation: ◯
Navigation device: It is not
Audio: It is not
CD player: ×

Gear ratios

CVT	1	2	3	4	5	6	7	Rev	Main
—	3.545	1.904	1.310	0.969	0.815	—	—	—	3.250

Available colors

black / Black Metallicwhite / Super White IIgreenMaroon (brown)OliveNavy blue / Dark blue mica metallicPurpleAshesYellow / Other YellowYellow-greenBlack (P)MagentaSilver / Other SilverRed / Super Red IIBlueDark cyan / Other Dark cyanPearlGold
