TOYOTA CORSA GX

TOYOTA CORSA

NL30 · GX

Description

Modification: GX
Chassis ID: NL30
Dates releasing: 1988.5~
Base price, ¥: Q-NL30
Body size: 3920x1625x1380
Interior (LxWxH): 1795x1350x1160
Wheelbase: 2380
Track f/r: 1385mm/1375mm
Full weight, kg: 880
Body type: Hatch
Doors / seats: 5 door / 5

Safe equipment

Driver's air bag: ×
Front passenger air bag: ×
Side airbags: ×
ABS: ×
TRC: ×
Belts w/ tensioner: ×
Belts w/ effort limiter: ×
Belts w/ holding: ×
Child-seat fixation: ×
Safety planks: ×
Brake assist: ×
Energy-absorbing body: ×
EBD: ×
Anti-theft device: ×
Additional equipment: ×

Comfort

Air conditioner: ×
Power window: ×
Central switch: ×
Steering column length: ×
Steering column height: ×
Cruise control: ×
Leather steering wheel: ×
Leather seats: —
Power front seat: ×
Power rear seat: ×
Wood panel: ×
Sunroof: ×
Alloy wheels: Option settings NO
Folding seat: split
Glass w/ UV filter: ×
Toned glasses: ×

Engine

Model: 1N-T
Type: water cooling inline 4 cylinder OHCturbo (Diesel)
Bore x stroke, mm: 74.0x84.5
Engine size, cc: 1453
Compression ratio: 22.0
Fuel injection: ボッシュ type 分配型(噴射ポンプ)
Max power, hp/rpm: 67ps(49kW)/4700rpm
Max torque, Nm/rpm: 13.3kg m(130.4N m)/2600rpm
Supercharger: Turbo
Fuel tank, liters: 45 l
Fuel: Diesel
Fuel consumption, l/100km: 0

Steering & suspension

Steering: Power assist equipped rack&pinion
Front suspension: Strut type Coil spring
Rear suspension: トレーリングリンクツイストビー&#12512
Front brake: disk
Rear brake: Drum
Front wheel: 155SR13
Rear wheel: 155SR13
Min turn diameter, m: 4.5

Gearbox

Number of stages: 5MT
Drive: FF
LSD: ----

Exterior equipment

Front fog lights: ×
Rear fog lights: ×
Xenon: ×
Extra front lights: ×
Spoilers (f / r): × / ×
Wiper: ✓

Navigation & sound

Navigation: ×
Navigation device: It is not
Audio: AMラジオ
CD player: ×

Gear ratios

CVT	1	2	3	4	5	6	7	Rev	Main
—	—	—	—	—	—	—	—	—	----

Available colors

blackwhitegreenMaroon (brown) / Red micaOliveNavy bluePurpleAshesYellowYellow-greenBlack (P)MagentaSilver / Light blue metallicRedBlue / Blue mica metallicDark cyanPearlGold
