TOYOTA CROWN STATIONWAGON ROYAL EXTRA

TOYOTA CROWN STATIONWAGON

LS130W · ROYAL EXTRA

Description

Modification: ROYAL EXTRA
Chassis ID: LS130W
Dates releasing: 1995.12~
Base price, ¥: KD-LS130W
Body size: 4860x1725x1550
Interior (LxWxH): 1895x1475x1230
Wheelbase: 2730
Track f/r: 1455mm/1400mm
Full weight, kg: 1620
Body type: Wagon
Doors / seats: 5 door / 5

Safe equipment

Driver's air bag: ✓
Front passenger air bag: ×
Side airbags: ×
ABS: ✓
TRC: ×
Belts w/ tensioner: ×
Belts w/ effort limiter: ×
Belts w/ holding: ✓
Child-seat fixation: ×
Safety planks: ✓
Brake assist: ×
Energy-absorbing body: ×
EBD: ×
Anti-theft device: ×
Additional equipment: ×

Comfort

Air conditioner: Full Auto
Power window: ✓
Central switch: ✓
Steering column length: ×
Steering column height: ✓
Cruise control: ×
Leather steering wheel: ◯
Leather seats: —
Power front seat: ×
Power rear seat: ×
Wood panel: ◯
Sunroof: ◯
Alloy wheels: Option settings YES
Folding seat: split
Glass w/ UV filter: ×
Toned glasses: ×

Engine

Model: 2L-TE
Type: water cooling inline 4 cylinder OHCturbo (Diesel)
Bore x stroke, mm: 92.0x92.0
Engine size, cc: 2446
Compression ratio: 21.0
Fuel injection: ボッシュ type 分配型燃料噴射ポンプ〈&#
Max power, hp/rpm: 97ps(71kW)/3800rpm
Max torque, Nm/rpm: 22.5kg m(220.6N m)/2400rpm
Supercharger: Turbo
Fuel tank, liters: 64 l
Fuel: Diesel
Fuel consumption, l/100km: 0

Steering & suspension

Steering: Other
Front suspension: Double wishbone type コイルばね
Rear suspension: トレーリングリンク Axle コイルばね
Front brake: Ventilated disk
Rear brake: Drum
Front wheel: 195/70R14 91S
Rear wheel: 195/70R14 91S
Min turn diameter, m: 5.5

Gearbox

Number of stages: 4AT
Drive: FR
LSD: ----

Exterior equipment

Front fog lights: ✓
Rear fog lights: ×
Xenon: ×
Extra front lights: ×
Spoilers (f / r): × / ×
Wiper: ×

Navigation & sound

Navigation: ×
Navigation device: It is not
Audio: AM/FM radio with CS player
CD player: ×

Gear ratios

CVT	1	2	3	4	5	6	7	Rev	Main
—	2.531	1.531	1.000	0.705	—	—	—	—	1.880

Available colors

blackwhite / Super White IIgreenMaroon (brown)OliveNavy blue / Other Navy bluePurpleAshesYellowYellow-greenBlack (P)MagentaSilverRedBlueDark cyan / Other Dark cyanPearl / Other PearlGold
