TOYOTA ESTIMA LUCIDA X

TOYOTA ESTIMA LUCIDA

CXR10G · X

Description

Modification: X
Chassis ID: CXR10G
Dates releasing: 1993.8~
Base price, ¥: Y-CXR10G
Body size: 4690x1690x1910
Interior (LxWxH): 2890x1520x1285
Wheelbase: 2860
Track f/r: 1450mm/1440mm
Full weight, kg: 1670
Body type: MV 1Box
Doors / seats: 4 door / 8

Safe equipment

Driver's air bag: ◯
Front passenger air bag: ×
Side airbags: ×
ABS: ◯
TRC: ×
Belts w/ tensioner: ×
Belts w/ effort limiter: ×
Belts w/ holding: ✓
Child-seat fixation: ×
Safety planks: ✓
Brake assist: ×
Energy-absorbing body: ×
EBD: ×
Anti-theft device: ×
Additional equipment: ×

Comfort

Air conditioner: Dual air conditioning
Power window: ✓
Central switch: ✓
Steering column length: ×
Steering column height: ✓
Cruise control: ×
Leather steering wheel: ×
Leather seats: —
Power front seat: ×
Power rear seat: ×
Wood panel: ◯
Sunroof: 特殊形状
Alloy wheels: Option settings YES
Folding seat: ×
Glass w/ UV filter: ×
Toned glasses: ×

Engine

Model: 3C-TE
Type: inline 4 cylinder OHCIC-turbo (Diesel)
Bore x stroke, mm: 86.0x94.0
Engine size, cc: 2184
Compression ratio: 22.0
Fuel injection: EFI(電子制御分配型)
Max power, hp/rpm: 100ps(74kW)/4200rpm
Max torque, Nm/rpm: 22.0kg m(215.7N m)/2600rpm
Supercharger: IC turbo
Fuel tank, liters: 60 l
Fuel: Diesel
Fuel consumption, l/100km: 0

Steering & suspension

Steering: Power assist equipped rack&pinion
Front suspension: Strut type Coil spring (stabilizer attaching)
Rear suspension: 4-link Coil spring
Front brake: Ventilated disk
Rear brake: Drum
Front wheel: 185SR14
Rear wheel: 185SR14
Min turn diameter, m: 5.6

Gearbox

Number of stages: 5MT
Drive: Mid-ship
LSD: ----

Exterior equipment

Front fog lights: ✓
Rear fog lights: ×
Xenon: ×
Extra front lights: ×
Spoilers (f / r): × / ◯
Wiper: ✓

Navigation & sound

Navigation: ×
Navigation device: It is not
Audio: AM/FMラジオ
CD player: ×

Gear ratios

CVT	1	2	3	4	5	6	7	Rev	Main
—	3.954	2.141	1.384	1.000	0.850	—	—	—	4.091

Available colors

blackwhitegreen / Other greenMaroon (brown)OliveNavy bluePurpleAshes / Bluish gray metallicYellowYellow-greenBlack (P)MagentaSilver / Other SilverRed / Other RedBlueDark cyan / Other Dark cyanPearlGold
