JDM Vehicle Catalog

Vehicle Specs

TOYOTA HIACE VAN DX

TOYOTA HIACE VAN

KDH200V · DX

Description

Modification: DX
Chassis ID: KDH200V
Dates releasing: 2004.8~
Base price, ¥: KR-KDH200V
Body size: 4695x1695x1980
Interior (LxWxH): ----x----x----
Wheelbase: 2570
Track f/r: 1470mm/1465mm
Full weight, kg: 1760
Body type: Cab-over van
Doors / seats: 5 door / 3

Safe equipment

Driver's air bag: ✓
Front passenger air bag: ◯
Side airbags: ×
ABS: ✓
TRC: ×
Belts w/ tensioner: ✓
Belts w/ effort limiter: ✓
Belts w/ holding: ×
Child-seat fixation: ×
Safety planks: ×
Brake assist: ✓
Energy-absorbing body: ×
EBD: ×
Anti-theft device: ×
Additional equipment: ×

Comfort

Air conditioner: Manual
Power window: ◯
Central switch: ✓
Steering column length: ×
Steering column height: ✓
Cruise control: ×
Leather steering wheel: ×
Leather seats: —
Power front seat: ×
Power rear seat: ×
Wood panel: ×
Sunroof: ×
Alloy wheels: ×
Folding seat: ×
Glass w/ UV filter: ✓
Toned glasses: ◯

Engine

Model: 2KD-FTV
Type: water cooling inline 4 cylinder DOHCturbo (Diesel)
Bore x stroke, mm: 92.0x93.8
Engine size, cc: 2494
Compression ratio: 18.5
Fuel injection: コモンレール type 燃料噴射システム
Max power, hp/rpm: 109ps(80kW)/3400rpm
Max torque, Nm/rpm: 26.5kg m(260N m)/1600~2600rpm
Supercharger: Turbo
Fuel tank, liters: 70 l
Fuel: Diesel
Fuel consumption, l/100km: 0

Steering & suspension

Steering: Power assist equipped rack&pinion
Front suspension: Double wishbone type トーションバースプリング
Rear suspension: Axle 半楕円板ばね
Front brake: Ventilated disk
Rear brake: Drum
Front wheel: 195/80R15 103/101L LT
Rear wheel: 195/80R15 107/105L LT
Min turn diameter, m: 5.0

Gearbox

Number of stages: 4AT
Drive: FR
LSD: ----

Exterior equipment

Front fog lights: ◯
Rear fog lights: ◯
Xenon: ×
Extra front lights: ×
Spoilers (f / r): × / ×
Wiper: ◯

Navigation & sound

Navigation: ◯
Navigation device: CD
Audio: AM/FMラジオ
CD player: ×

Gear ratios

CVT	1	2	3	4	5	6	7	Rev	Main
—	2.804	1.531	1.000	0.705	—	—	—	—	2.393

Available colors

blackwhitegreen / Dark green mica metallicMaroon (brown)OliveNavy blue / Dark blue mica metallicPurpleAshesYellow / Other YellowYellow-greenBlack (P)MagentaSilver / Silver metallicRedBlueDark cyanPearlGold
