TOYOTA HILUX PICK UP DOUBLECAB SR

TOYOTA HILUX PICK UP

LN107 · DOUBLECAB SR

Description

Modification: DOUBLECAB SR
Chassis ID: LN107
Dates releasing: 1991.8~
Base price, ¥: S-LN107
Body size: 4690x1690x1775
Interior (LxWxH): ----x----x----
Wheelbase: 2855
Track f/r: 1430mm/1425mm
Full weight, kg: 1630
Body type: Pickup
Doors / seats: 4 door / 5

Safe equipment

Driver's air bag: ×
Front passenger air bag: ×
Side airbags: ×
ABS: ×
TRC: ×
Belts w/ tensioner: ×
Belts w/ effort limiter: ×
Belts w/ holding: ✓
Child-seat fixation: ×
Safety planks: ×
Brake assist: ×
Energy-absorbing body: ×
EBD: ×
Anti-theft device: ×
Additional equipment: ×

Comfort

Air conditioner: ×
Power window: ×
Central switch: ×
Steering column length: ×
Steering column height: ✓
Cruise control: ×
Leather steering wheel: ×
Leather seats: —
Power front seat: ×
Power rear seat: ×
Wood panel: ×
Sunroof: ×
Alloy wheels: ×
Folding seat: ×
Glass w/ UV filter: ×
Toned glasses: ×

Engine

Model: 3L
Type: water cooling inline 4 cylinder OHC (Diesel)
Bore x stroke, mm: 96.0x96.0
Engine size, cc: 2779
Compression ratio: 22.2
Fuel injection: ポッシュ type 分配型(噴射ポンプ)
Max power, hp/rpm: 91ps(67kW)/4000rpm
Max torque, Nm/rpm: 19.2kg m(188.3N m)/2400rpm
Supercharger: ×
Fuel tank, liters: 65 l
Fuel: Diesel
Fuel consumption, l/100km: 0

Steering & suspension

Steering: Other
Front suspension: Double wishbone type トーションバー
Rear suspension: 半だ円リーフスプリング
Front brake: disk
Rear brake: Drum
Front wheel: 215R15-6
Rear wheel: 215R15-6
Min turn diameter, m: 6.1

Gearbox

Number of stages: 5MT
Drive: Part-time 4WD
LSD: ◯

Exterior equipment

Front fog lights: ◯
Rear fog lights: ×
Xenon: ×
Extra front lights: ×
Spoilers (f / r): ◯ / ×
Wiper: ×

Navigation & sound

Navigation: ×
Navigation device: It is not
Audio: AMラジオ
CD player: ×

Gear ratios

CVT	1	2	3	4	5	6	7	Rev	Main
—	3.928	2.333	1.451	1.000	0.851	—	—	—	4.743

Available colors

blackwhitegreenMaroon (brown)OliveNavy blue / Other Navy bluePurpleAshes / Other AshesYellowYellow-greenBlack (P)MagentaSilverRed / Red micaBlueDark cyanPearlGold
