TOYOTA HILUX SPORTS PICK UP DOUBLE CAB

TOYOTA HILUX SPORTS PICK UP

LN165 · DOUBLE CAB

Description

Modification: DOUBLE CAB
Chassis ID: LN165
Dates releasing: 1997.9~
Base price, ¥: KB-LN165
Body size: 4690x1690x1795
Interior (LxWxH): ----x----x----
Wheelbase: 2855
Track f/r: 1440mm/1425mm
Full weight, kg: 1720
Body type: Pickup
Doors / seats: 4 door / 5

Safe equipment

Driver's air bag: ✓
Front passenger air bag: ◯
Side airbags: ×
ABS: ✓
TRC: ×
Belts w/ tensioner: ✓
Belts w/ effort limiter: ✓
Belts w/ holding: ✓
Child-seat fixation: ×
Safety planks: ✓
Brake assist: ×
Energy-absorbing body: 採用
EBD: ×
Anti-theft device: ×
Additional equipment: ×

Comfort

Air conditioner: ×
Power window: ✓
Central switch: ✓
Steering column length: ×
Steering column height: ✓
Cruise control: ×
Leather steering wheel: ×
Leather seats: —
Power front seat: ×
Power rear seat: ×
Wood panel: ◯
Sunroof: ◯
Alloy wheels: Option settings YES
Folding seat: ×
Glass w/ UV filter: ×
Toned glasses: ×

Engine

Model: 2L-TE
Type: water cooling inline 4 cylinder OHCturbo (Diesel)
Bore x stroke, mm: 92.0x92.0
Engine size, cc: 2446
Compression ratio: 21.0
Fuel injection: EFI電子制御分配型噴射ポンプ
Max power, hp/rpm: 97ps(71kW)/3800rpm
Max torque, Nm/rpm: 24.5kg m(240.3N m)/2400rpm
Supercharger: Turbo
Fuel tank, liters: 65 l
Fuel: Diesel
Fuel consumption, l/100km: 0

Steering & suspension

Steering: Other
Front suspension: Double wishbone type トーションバー
Rear suspension: 半だ円リーフスプリング
Front brake: Ventilated disk
Rear brake: Drum
Front wheel: 215R15
Rear wheel: 215R15
Min turn diameter, m: 6.1

Gearbox

Number of stages: 4AT
Drive: Part-time 4WD
LSD: ◯

Exterior equipment

Front fog lights: ◯
Rear fog lights: ×
Xenon: ×
Extra front lights: ×
Spoilers (f / r): × / ×
Wiper: ×

Navigation & sound

Navigation: ◯
Navigation device: It is not
Audio: It is not
CD player: ×

Gear ratios

CVT	1	2	3	4	5	6	7	Rev	Main
—	2.804	1.531	1.000	0.753	—	—	—	—	2.393

Available colors

blackwhitegreen / Dark green mica metallicMaroon (brown)OliveNavy blue / Dark blue mica metallicPurple / Other PurpleAshesYellowYellow-greenBlack (P)MagentaSilverRed / Red mica metallicBlueDark cyan / Other Dark cyanPearlGold
