TOYOTA KLUGER L 2.4S X PACKAGE

TOYOTA KLUGER L

ACU20W · 2.4S X PACKAGE

Description

Modification: 2.4S X PACKAGE
Chassis ID: ACU20W
Dates releasing: 2003.8~
Base price, ¥: UA-ACU20W
Body size: 4690x1825x1685
Interior (LxWxH): 2015x1500x1220
Wheelbase: 2715
Track f/r: 1575mm/1555mm
Full weight, kg: 1570
Body type: SUV
Doors / seats: 5 door / 5

Safe equipment

Driver's air bag: ✓
Front passenger air bag: ✓
Side airbags: ◯
ABS: ✓
TRC: ×
Belts w/ tensioner: ✓
Belts w/ effort limiter: ✓
Belts w/ holding: ✓
Child-seat fixation: ✓
Safety planks: ✓
Brake assist: ✓
Energy-absorbing body: ×
EBD: ✓
Anti-theft device: ✓
Additional equipment: ×

Comfort

Air conditioner: Full Auto
Power window: ✓
Central switch: ✓
Steering column length: ×
Steering column height: ✓
Cruise control: ×
Leather steering wheel: ✓
Leather seats: —
Power front seat: ×
Power rear seat: ×
Wood panel: ×
Sunroof: ×
Alloy wheels: Option settings NO
Folding seat: split
Glass w/ UV filter: ✓
Toned glasses: ✓

Engine

Model: 2AZ-FE
Type: water cooling inline 4 cylinder DOHC 16-valves
Bore x stroke, mm: 88.5x96.0
Engine size, cc: 2362
Compression ratio: 9.6
Fuel injection: EFI
Max power, hp/rpm: 160ps(118kW)/5600rpm
Max torque, Nm/rpm: 22.5kg m(221N m)/4000rpm
Supercharger: ×
Fuel tank, liters: 72 l
Fuel: Regular unleaded gasoline
Fuel consumption, l/100km: 9.1

Steering & suspension

Steering: Power assist equipped rack&pinion
Front suspension: Strut type Coil spring
Rear suspension: Strut type Coil spring
Front brake: Ventilated disk
Rear brake: disk
Front wheel: 215/70R16 99S
Rear wheel: 215/70R16 99S
Min turn diameter, m: 5.6

Gearbox

Number of stages: 4AT
Drive: FF
LSD: ----

Exterior equipment

Front fog lights: ×
Rear fog lights: ◯
Xenon: ×
Extra front lights: ×
Spoilers (f / r): × / ×
Wiper: ✓

Navigation & sound

Navigation: ◯
Navigation device: DVD
Audio: It is not
CD player: ×

Gear ratios

CVT	1	2	3	4	5	6	7	Rev	Main
—	3.943	2.197	1.413	1.020	—	—	—	—	3.145

Available colors

blackwhitegreenMaroon (brown)OliveNavy bluePurpleAshesYellowYellow-greenBlack (P)MagentaSilverRedBlueDark cyanPearl / White Pearl Crystal ShineGold / Other Gold
