Vehicle Specs

TOYOTA LAND CRUISER 100 VX

TOYOTA LAND CRUISER 100

HDJ101K · VX

Description

Modification: VX
Chassis ID: HDJ101K
Dates releasing: 1999.8~
Base price, ¥: KG-HDJ101K
Body size: 4890x1940x1860
Interior (LxWxH): ----x----x----
Wheelbase: 2850
Track f/r: 1620mm/1615mm
Full weight, kg: 2520
Body type: SUV
Doors / seats: 5 door / 5

Safe equipment

Driver's air bag: ✓
Front passenger air bag: ✓
Side airbags: ×
ABS: ✓
TRC: ×
Belts w/ tensioner: ✓
Belts w/ effort limiter: ✓
Belts w/ holding: ✓
Child-seat fixation: ✓
Safety planks: ✓
Brake assist: ×
Energy-absorbing body: ×
EBD: ×
Anti-theft device: ×
Additional equipment: ×

Comfort

Air conditioner: Full Auto
Power window: ✓
Central switch: ✓
Steering column length: ×
Steering column height: ✓
Cruise control: ×
Leather steering wheel: ×
Leather seats: —
Power front seat: ×
Power rear seat: ×
Wood panel: ×
Sunroof: ×
Alloy wheels: Option settings YES
Folding seat: split
Glass w/ UV filter: ✓
Toned glasses: ×

Engine

Model: 1HD-FTE
Type: water cooling inline 6 cylinder OHC 24-valves IC-turbo (Diesel)
Bore x stroke, mm: 94.0x100.0
Engine size, cc: 4163
Compression ratio: 18.8
Fuel injection: 電子制御 type 分配型燃料噴射ポンプ
Max power, hp/rpm: 205ps(151kW)/3400rpm
Max torque, Nm/rpm: 44.0kg m(431.5N m)/1800rpm
Supercharger: IC turbo
Fuel tank, liters: 96 l
Fuel: Diesel
Fuel consumption, l/100km: 0

Steering & suspension

Steering: Power assist equipped rack&pinion
Front suspension: Double wishbone type Independent suspension
Rear suspension: トレーリングリンク Axle コイルばね (stabiliz
Front brake: Ventilated disk
Rear brake: Ventilated disk
Front wheel: 275/70R16
Rear wheel: 275/70R16
Min turn diameter, m: 5.9

Gearbox

Number of stages: 4AT
Drive: Full-time 4WD
LSD: ◯

Exterior equipment

Front fog lights: ✓
Rear fog lights: ×
Xenon: ×
Extra front lights: ×
Spoilers (f / r): ◯ / ◯
Wiper: ✓

Navigation & sound

Navigation: ×
Navigation device: It is not
Audio: It is not
CD player: ×

Gear ratios

CVT	1	2	3	4	5	6	7	Rev	Main
—	2.950	1.530	1.000	0.765	—	—	—	—	2.678

Available colors

blackwhitegreen / Dark green micaMaroon (brown)OliveNavy blue / Dark blue micaPurpleAshes / Other AshesYellowYellow-greenBlack (P)MagentaSilver / Other SilverRed / Red micaBlueDark cyanPearlGold
