TOYOTA OPA I S PACKAGE

TOYOTA OPA

ZCT10 · I S PACKAGE

Description

Modification: I S PACKAGE
Chassis ID: ZCT10
Dates releasing: 2002.6~
Base price, ¥: UA-ZCT10
Body size: 4250x1695x1525
Interior (LxWxH): 2025x1400x1250
Wheelbase: 2700
Track f/r: 1475mm/1460mm
Full weight, kg: 1210
Body type: MV 1Box
Doors / seats: 5 door / 5

Safe equipment

Driver's air bag: ✓
Front passenger air bag: ✓
Side airbags: ×
ABS: ✓
TRC: ×
Belts w/ tensioner: ✓
Belts w/ effort limiter: ✓
Belts w/ holding: ✓
Child-seat fixation: ✓
Safety planks: ✓
Brake assist: ✓
Energy-absorbing body: 採用
EBD: ✓
Anti-theft device: ×
Additional equipment: ×

Comfort

Air conditioner: Full Auto
Power window: ✓
Central switch: ✓
Steering column length: ×
Steering column height: ✓
Cruise control: ×
Leather steering wheel: ✓
Leather seats: —
Power front seat: ×
Power rear seat: ×
Wood panel: ◯
Sunroof: ◯
Alloy wheels: 15 inches standard
Folding seat: split
Glass w/ UV filter: ✓
Toned glasses: ✓

Engine

Model: 1ZZ-FE
Type: inline 4 cylinder DOHC 16-valves
Bore x stroke, mm: 79.0x91.5
Engine size, cc: 1794
Compression ratio: 10.0
Fuel injection: 電子制御 type 燃料噴射装置(EFI)
Max power, hp/rpm: 132ps(97kW)/6000rpm
Max torque, Nm/rpm: 17.3kg m(170N m)/4200rpm
Supercharger: ×
Fuel tank, liters: 60 l
Fuel: Regular unleaded gasoline
Fuel consumption, l/100km: 6.2

Steering & suspension

Steering: Power assist equipped rack&pinion
Front suspension: Strut
Rear suspension: トーションビーム
Front brake: disk
Rear brake: disk
Front wheel: 195/65R15 91S
Rear wheel: 195/65R15 91S
Min turn diameter, m: 5.3

Gearbox

Number of stages: 4AT
Drive: FF
LSD: ----

Exterior equipment

Front fog lights: ✓
Rear fog lights: ×
Xenon: ✓
Extra front lights: ×
Spoilers (f / r): ◯ / ✓
Wiper: ✓

Navigation & sound

Navigation: ◯
Navigation device: DVD
Audio: AM/FM radio with MD player
CD player: 連装

Gear ratios

CVT	1	2	3	4	5	6	7	Rev	Main
—	2.847	1.552	1.000	0.700	—	—	—	—	2.343

Available colors

black / black micawhitegreen / Other greenMaroon (brown)OliveNavy bluePurpleAshesYellowYellow-greenBlack (P)MagentaSilverRed / Red mica metallicBlueDark cyanPearl / Other PearlGold / Beige Metallic
