JDM Vehicle Catalog

Vehicle Specs

TOYOTA PIXIS TRUCK EXTRA SAIIIt

TOYOTA PIXIS TRUCK

S510U · EXTRA SAIIIt

Description

Modification: EXTRA SAIIIt
Chassis ID: S510U
Dates releasing: 2018.6~
Base price, ¥: EBD-S510U
Body size: 3395x1475x1780
Interior (LxWxH): ----x----x----
Wheelbase: 1900
Track f/r: 1305mm/1300mm
Full weight, kg: 810
Body type: Kei truck
Doors / seats: 2 door / 2

Safe equipment

Driver's air bag: ✓
Front passenger air bag: ◯
Side airbags: ×
ABS: ✓
TRC: ✓
Belts w/ tensioner: ✓
Belts w/ effort limiter: ✓
Belts w/ holding: ×
Child-seat fixation: ×
Safety planks: ×
Brake assist: ×
Energy-absorbing body: 採用
EBD: ✓
Anti-theft device: ×
Additional equipment: VSC

Comfort

Air conditioner: Manual
Power window: ✓
Central switch: ✓
Steering column length: ×
Steering column height: ×
Cruise control: ×
Leather steering wheel: ×
Leather seats: —
Power front seat: ×
Power rear seat: ×
Wood panel: ×
Sunroof: ×
Alloy wheels: Option settings NO
Folding seat: ×
Glass w/ UV filter: ✓
Toned glasses: ✓

Engine

Model: KF
Type: water cooling inline 3 cylinder DOHC 12-valves
Bore x stroke, mm: 63.0x70.4
Engine size, cc: 658
Compression ratio: 11.3
Fuel injection: EFI
Max power, hp/rpm: 46ps(34kW)/5700rpm
Max torque, Nm/rpm: 6.1kg m(60N m)/4000rpm
Supercharger: ×
Fuel tank, liters: 35 l
Fuel: Regular unleaded gasoline
Fuel consumption, l/100km: 5.3

Steering & suspension

Steering: Power assist equipped rack&pinion
Front suspension: L型ロアアーム& McPherson Strut type Coil spring
Rear suspension: Axle リーフスプリング
Front brake: disk
Rear brake: Drum
Front wheel: 145R12LT
Rear wheel: 145R12LT
Min turn diameter, m: 3.6

Gearbox

Number of stages: 5MT
Drive: Part-time 4WD
LSD: ----

Exterior equipment

Front fog lights: ✓
Rear fog lights: ×
Xenon: ×
Extra front lights: ×
Spoilers (f / r): × / ×
Wiper: ×

Navigation & sound

Navigation: ×
Navigation device: It is not
Audio: It is not
CD player: ×

Gear ratios

CVT	1	2	3	4	5	6	7	Rev	Main
—	4.059	2.389	1.636	1.000	0.742	—	—	—	4.128

Available colors

black / Black mica metallicwhitegreenMaroon (brown)Olive / Other OliveNavy bluePurpleAshesYellowYellow-greenBlack (P) / Other Black (P)Magenta / Light rose-metallicSilver / Bright silver metallicRedBlueDark cyan / Other Dark cyanPearlGold / Other Gold
