JDM Vehicle Catalog

Vehicle Specs

TOYOTA PLATZ 1.0F

TOYOTA PLATZ

SCP11 · 1.0F

Description

Modification: 1.0F
Chassis ID: SCP11
Dates releasing: 2002.8~
Base price, ¥: UA-SCP11
Body size: 4180x1660x1500
Interior (LxWxH): 1850x1380x1260
Wheelbase: 2370
Track f/r: 1450mm/1430mm
Full weight, kg: 880
Body type: Sedan
Doors / seats: 4 door / 5

Safe equipment

Driver's air bag: ✓
Front passenger air bag: ✓
Side airbags: ×
ABS: ✓
TRC: ×
Belts w/ tensioner: ✓
Belts w/ effort limiter: ✓
Belts w/ holding: ✓
Child-seat fixation: ×
Safety planks: ✓
Brake assist: ✓
Energy-absorbing body: 採用
EBD: ✓
Anti-theft device: ×
Additional equipment: ×

Comfort

Air conditioner: Manual
Power window: ✓
Central switch: ✓
Steering column length: ×
Steering column height: ✓
Cruise control: ×
Leather steering wheel: ◯
Leather seats: —
Power front seat: ×
Power rear seat: ×
Wood panel: ×
Sunroof: ×
Alloy wheels: Option settings NO
Folding seat: 一体
Glass w/ UV filter: ✓
Toned glasses: ×

Engine

Model: 1SZ-FE
Type: inline 4 cylinder DOHC
Bore x stroke, mm: 69.0x66.7
Engine size, cc: 997
Compression ratio: 10.0
Fuel injection: EFI
Max power, hp/rpm: 70ps(51kW)/6000rpm
Max torque, Nm/rpm: 9.5kg m(93N m)/4100rpm
Supercharger: ×
Fuel tank, liters: 45 l
Fuel: Regular unleaded gasoline
Fuel consumption, l/100km: 4.6

Steering & suspension

Steering: Power assist equipped rack&pinion
Front suspension: Strut type Coil spring
Rear suspension: Torsion beam
Front brake: Ventilated disk
Rear brake: Drum
Front wheel: 155/80R13 79S
Rear wheel: 155/80R13 79S
Min turn diameter, m: 4.9

Gearbox

Number of stages: 5MT
Drive: FF
LSD: ----

Exterior equipment

Front fog lights: ◯
Rear fog lights: ◯
Xenon: ×
Extra front lights: ×
Spoilers (f / r): × / ×
Wiper: ×

Navigation & sound

Navigation: ◯
Navigation device: It is not
Audio: It is not
CD player: ×

Gear ratios

CVT	1	2	3	4	5	6	7	Rev	Main
—	3.545	1.913	1.310	0.973	0.804	—	—	—	3.214

Available colors

blackwhitegreen / Dark green micaMaroon (brown)OliveNavy blue / Dark blue mica metallicPurpleAshesYellowYellow-greenBlack (P) / Other Black (P)MagentaSilver / Silver metallicRed / Red mica metallicBlueDark cyanPearl / Pearl WhiteGold / Beige Metallic
