JDM Vehicle Catalog

Vehicle Specs

TOYOTA PLATZ 1.3X

TOYOTA PLATZ

NCP16 · 1.3X

Description

Modification: 1.3X
Chassis ID: NCP16
Dates releasing: 1999.8~
Base price, ¥: GH-NCP16
Body size: 4145x1660x1510
Interior (LxWxH): 1855x1380x1265
Wheelbase: 2370
Track f/r: 1450mm/1420mm
Full weight, kg: 990
Body type: Sedan
Doors / seats: 4 door / 5

Safe equipment

Driver's air bag: ✓
Front passenger air bag: ✓
Side airbags: ×
ABS: ✓
TRC: ×
Belts w/ tensioner: ✓
Belts w/ effort limiter: ✓
Belts w/ holding: ✓
Child-seat fixation: ×
Safety planks: ✓
Brake assist: ×
Energy-absorbing body: ×
EBD: ×
Anti-theft device: ×
Additional equipment: ×

Comfort

Air conditioner: Full Auto
Power window: ✓
Central switch: ✓
Steering column length: ×
Steering column height: ✓
Cruise control: ×
Leather steering wheel: ◯
Leather seats: —
Power front seat: ×
Power rear seat: ×
Wood panel: ×
Sunroof: ×
Alloy wheels: Option settings YES
Folding seat: 一体
Glass w/ UV filter: ✓
Toned glasses: ×

Engine

Model: 2NZ-FE
Type: inline 4 cylinder DOHC
Bore x stroke, mm: 75.0x73.5
Engine size, cc: 1298
Compression ratio: 10.5
Fuel injection: EFI
Max power, hp/rpm: 88ps(65kW)/6000rpm
Max torque, Nm/rpm: 12.3kg m(120.6N m)/4400rpm
Supercharger: ×
Fuel tank, liters: 45 l
Fuel: Regular unleaded gasoline
Fuel consumption, l/100km: 5.5

Steering & suspension

Steering: Power assist equipped rack&pinion
Front suspension: Strut type Coil spring
Rear suspension: トレーリング Axle Coil spring
Front brake: Ventilated disk
Rear brake: Drum
Front wheel: 155/80R13 79S
Rear wheel: 155/80R13 79S
Min turn diameter, m: 4.3

Gearbox

Number of stages: 5MT
Drive: Full-time 4WD
LSD: ----

Exterior equipment

Front fog lights: ◯
Rear fog lights: ◯
Xenon: ×
Extra front lights: ×
Spoilers (f / r): × / ×
Wiper: ×

Navigation & sound

Navigation: ◯
Navigation device: It is not
Audio: AM/FM radio with CS player
CD player: 単装

Gear ratios

CVT	1	2	3	4	5	6	7	Rev	Main
—	3.545	1.904	1.310	0.969	0.815	—	—	—	3.250

Available colors

blackwhite / Super White IIgreen / Dark green micaMaroon (brown)OliveNavy bluePurpleAshesYellowYellow-greenBlack (P)MagentaSilverRed / Super Red VBlue / Dark blue micaDark cyanPearlGold / Champagne metallic
