TOYOTA RAV4J J V TYPE X

TOYOTA RAV4J

SXA11W · J V TYPE X

Description

Modification: J V TYPE X
Chassis ID: SXA11W
Dates releasing: 1998.8~
Base price, ¥: GF-SXA11W
Body size: 4115x1760x1640
Interior (LxWxH): 1645x1410x1195
Wheelbase: 2410
Track f/r: 1480mm/1490mm
Full weight, kg: 1330
Body type: SUV
Doors / seats: 5 door / 5

Safe equipment

Driver's air bag: ✓
Front passenger air bag: ✓
Side airbags: ×
ABS: ✓
TRC: ×
Belts w/ tensioner: ✓
Belts w/ effort limiter: ✓
Belts w/ holding: ✓
Child-seat fixation: ✓
Safety planks: ✓
Brake assist: ×
Energy-absorbing body: 採用
EBD: ×
Anti-theft device: ×
Additional equipment: ×

Comfort

Air conditioner: Full Auto
Power window: ✓
Central switch: ✓
Steering column length: ×
Steering column height: ✓
Cruise control: ×
Leather steering wheel: ◯
Leather seats: —
Power front seat: ×
Power rear seat: ×
Wood panel: ◯
Sunroof: ◯
Alloy wheels: 16 inches standard
Folding seat: split
Glass w/ UV filter: ×
Toned glasses: ✓

Engine

Model: 3S-FE
Type: inline 4 cylinder DOHC 16-valves
Bore x stroke, mm: 86x86
Engine size, cc: 1998
Compression ratio: 9.5
Fuel injection: EFI
Max power, hp/rpm: 135ps(99kW)/6000rpm
Max torque, Nm/rpm: 18.5kg m(181.4N m)/4400rpm
Supercharger: ×
Fuel tank, liters: 58 l
Fuel: Regular unleaded gasoline
Fuel consumption, l/100km: 9.4

Steering & suspension

Steering: Power assist equipped rack&pinion
Front suspension: McPherson Strut type Coil spring
Rear suspension: Double wishbone type Coil spring
Front brake: Ventilated disk
Rear brake: Drum
Front wheel: 235/60R16
Rear wheel: 235/60R16
Min turn diameter, m: 5.4

Gearbox

Number of stages: 4AT
Drive: Full-time 4WD
LSD: ◯

Exterior equipment

Front fog lights: ◯
Rear fog lights: ×
Xenon: ×
Extra front lights: ×
Spoilers (f / r): ◯ / ✓
Wiper: ✓

Navigation & sound

Navigation: ◯
Navigation device: It is not
Audio: It is not
CD player: ×

Gear ratios

CVT	1	2	3	4	5	6	7	Rev	Main
—	2.810	1.549	1.000	0.734	—	—	—	—	2.296

Available colors

blackwhitegreenMaroon (brown)OliveNavy bluePurpleAshesYellowYellow-greenBlack (P)MagentaSilver / Other SilverRedBlueDark cyanPearlGold
