JDM Vehicle Catalog

Vehicle Specs

TOYOTA RAV4J J X

TOYOTA RAV4J

ZCA25W · J X

Description

Modification: J X
Chassis ID: ZCA25W
Dates releasing: 2004.2~
Base price, ¥: CBA-ZCA25W
Body size: 3760x1735x1670
Interior (LxWxH): 1735x1465x1220
Wheelbase: 2280
Track f/r: 1510mm/1500mm
Full weight, kg: 1160
Body type: SUV
Doors / seats: 3 door / 4

Safe equipment

Driver's air bag: ✓
Front passenger air bag: ✓
Side airbags: ◯
ABS: ✓
TRC: ×
Belts w/ tensioner: ✓
Belts w/ effort limiter: ✓
Belts w/ holding: ✓
Child-seat fixation: ✓
Safety planks: ✓
Brake assist: ✓
Energy-absorbing body: 採用
EBD: ✓
Anti-theft device: ◯
Additional equipment: ×

Comfort

Air conditioner: Manual
Power window: ✓
Central switch: ✓
Steering column length: ×
Steering column height: ✓
Cruise control: ×
Leather steering wheel: ×
Leather seats: —
Power front seat: ×
Power rear seat: ×
Wood panel: ×
Sunroof: ×
Alloy wheels: Option settings NO
Folding seat: split
Glass w/ UV filter: ✓
Toned glasses: ×

Engine

Model: 1ZZ-FE
Type: inline 4 cylinder DOHC
Bore x stroke, mm: 79.0x91.5
Engine size, cc: 1794
Compression ratio: 10
Fuel injection: EFI
Max power, hp/rpm: 125ps(92kW)/6000rpm
Max torque, Nm/rpm: 16.4kg m(161N m)/4200rpm
Supercharger: ×
Fuel tank, liters: 57 l
Fuel: Regular unleaded gasoline
Fuel consumption, l/100km: 6.9

Steering & suspension

Steering: Power assist equipped rack&pinion
Front suspension: McPherson Strut type Coil spring (stabilizer attaching)
Rear suspension: Double wishbone type Coil spring (stabilizer attaching)
Front brake: Ventilated disk
Rear brake: Drum
Front wheel: 215/70R16
Rear wheel: 215/70R16
Min turn diameter, m: 5.0

Gearbox

Number of stages: 4AT
Drive: FF
LSD: ----

Exterior equipment

Front fog lights: ×
Rear fog lights: ×
Xenon: ×
Extra front lights: ×
Spoilers (f / r): × / ×
Wiper: ×

Navigation & sound

Navigation: ×
Navigation device: It is not
Audio: It is not
CD player: ×

Gear ratios

CVT	1	2	3	4	5	6	7	Rev	Main
—	2.847	1.552	1.000	0.700	—	—	—	—	2.343

Available colors

blackwhitegreenMaroon (brown)OliveNavy bluePurpleAshesYellowYellow-greenBlack (P)MagentaSilverRedBlue / Blue micaDark cyanPearl / White Pearl Crystal ShineGold
