TOYOTA SPRINTER CARIB ROSSO

TOYOTA SPRINTER CARIB

AE111G · ROSSO

Description

Modification: ROSSO
Chassis ID: AE111G
Dates releasing: 1999.4~
Base price, ¥: GF-AE111G
Body size: 4320x1690x1490
Interior (LxWxH): 1815x1425x1200
Wheelbase: 2465
Track f/r: 1460mm/1450mm
Full weight, kg: 1120
Body type: Wagon
Doors / seats: 5 door / 5

Safe equipment

Driver's air bag: ✓
Front passenger air bag: ✓
Side airbags: ×
ABS: ✓
TRC: ×
Belts w/ tensioner: ✓
Belts w/ effort limiter: ✓
Belts w/ holding: ✓
Child-seat fixation: ✓
Safety planks: ✓
Brake assist: ×
Energy-absorbing body: ×
EBD: ×
Anti-theft device: ×
Additional equipment: ×

Comfort

Air conditioner: Manual
Power window: ✓
Central switch: ✓
Steering column length: ×
Steering column height: ✓
Cruise control: ×
Leather steering wheel: ×
Leather seats: —
Power front seat: ×
Power rear seat: ×
Wood panel: ✓
Sunroof: ◯
Alloy wheels: Option settings YES
Folding seat: split
Glass w/ UV filter: ✓
Toned glasses: ✓

Engine

Model: 4A-FE
Type: inline 4 cylinder DOHC 16-valves
Bore x stroke, mm: 81.0x77.0
Engine size, cc: 1587
Compression ratio: 9.5
Fuel injection: EFI
Max power, hp/rpm: 110ps(81kW)/5800rpm
Max torque, Nm/rpm: 15.2kg m(149.1N m)/4600rpm
Supercharger: ×
Fuel tank, liters: 50 l
Fuel: Regular unleaded gasoline
Fuel consumption, l/100km: 7.2

Steering & suspension

Steering: Power assist equipped rack&pinion
Front suspension: McPherson Strut type Coil spring
Rear suspension: デュアルリンク Strut type Coil spring
Front brake: Ventilated disk
Rear brake: Drum
Front wheel: 175/65R14 82S
Rear wheel: 175/65R14 82S
Min turn diameter, m: 4.8

Gearbox

Number of stages: 4AT
Drive: FF
LSD: ----

Exterior equipment

Front fog lights: ×
Rear fog lights: ×
Xenon: ×
Extra front lights: ×
Spoilers (f / r): × / ✓
Wiper: ✓

Navigation & sound

Navigation: ×
Navigation device: It is not
Audio: It is not
CD player: ×

Gear ratios

CVT	1	2	3	4	5	6	7	Rev	Main
—	3.643	2.008	1.296	0.892	—	—	—	—	2.977

Available colors

black / Black MetallicwhitegreenMaroon (brown)OliveNavy bluePurpleAshesYellowYellow-greenBlack (P)MagentaSilverRed / Super Red IIBlueDark cyanPearlGold
