TOYOTA SPRINTER CIELO GT

TOYOTA SPRINTER CIELO

AE92 · GT

Description

Modification: GT
Chassis ID: AE92
Dates releasing: 1989.5~
Base price, ¥: E-AE92
Body size: 4255x1655x1360
Interior (LxWxH): 1780x1360x1150
Wheelbase: 2430
Track f/r: 1445mm/1425mm
Full weight, kg: 1050
Body type: Sedan
Doors / seats: 5 door / 5

Safe equipment

Driver's air bag: ×
Front passenger air bag: ×
Side airbags: ×
ABS: ×
TRC: ×
Belts w/ tensioner: ×
Belts w/ effort limiter: ×
Belts w/ holding: ×
Child-seat fixation: ×
Safety planks: ×
Brake assist: ×
Energy-absorbing body: ×
EBD: ×
Anti-theft device: ×
Additional equipment: ×

Comfort

Air conditioner: ×
Power window: ◯
Central switch: ◯
Steering column length: ×
Steering column height: ✓
Cruise control: ◯
Leather steering wheel: ×
Leather seats: —
Power front seat: ×
Power rear seat: ×
Wood panel: ×
Sunroof: ◯
Alloy wheels: Option settings YES
Folding seat: split
Glass w/ UV filter: ×
Toned glasses: ×

Engine

Model: 4A-GE
Type: water cooling inline 4 cylinder DOHC 16-valves
Bore x stroke, mm: 81.0x77.0
Engine size, cc: 1587
Compression ratio: 10.3
Fuel injection: EFI
Max power, hp/rpm: 140ps(103kW)/7200rpm
Max torque, Nm/rpm: 15.0kg m(147.1N m)/6000rpm
Supercharger: ×
Fuel tank, liters: 50 l
Fuel: Unleaded premium gasoline
Fuel consumption, l/100km: 8.2

Steering & suspension

Steering: Power assist equipped rack&pinion
Front suspension: Strut type Coil spring スタビライザー付
Rear suspension: Strut type Coil spring スタビライザー付
Front brake: Ventilated disk
Rear brake: disk
Front wheel: 185/60R14 82H
Rear wheel: 185/60R14 82H
Min turn diameter, m: 4.9

Gearbox

Number of stages: 5MT
Drive: FF
LSD: ----

Exterior equipment

Front fog lights: ✓
Rear fog lights: ×
Xenon: ×
Extra front lights: ×
Spoilers (f / r): × / ✓
Wiper: ✓

Navigation & sound

Navigation: ×
Navigation device: It is not
Audio: AM/FMラジオ
CD player: ×

Gear ratios

CVT	1	2	3	4	5	6	7	Rev	Main
—	3.166	1.904	1.310	0.969	0.815	—	—	—	3.250

Available colors

blackwhite / Super White IIgreenMaroon (brown)OliveNavy blue / Dark blue mica metallicPurpleAshes / Gray metallicYellowYellow-green / Grayish green metallicBlack (P)MagentaSilverRed / Red micaBlue / Other BlueDark cyanPearlGold
