VOLKSWAGEN GOLF WAGON E

VOLKSWAGEN GOLF WAGON

1JAVU · E

Description

Modification: E
Chassis ID: 1JAVU
Dates releasing: 2001.7~
Base price, ¥: GF-1JAVU
Body size: 4400x1735x1490
Interior (LxWxH): ----x----x----
Wheelbase: 2515
Track f/r: 1515mm/1495mm
Full weight, kg: 1310
Body type: Wagon
Doors / seats: 5 door / 5

Safe equipment

Driver's air bag: ✓
Front passenger air bag: ✓
Side airbags: ✓
ABS: ✓
TRC: ×
Belts w/ tensioner: ✓
Belts w/ effort limiter: ✓
Belts w/ holding: ✓
Child-seat fixation: ✓
Safety planks: ✓
Brake assist: ×
Energy-absorbing body: ×
EBD: ✓
Anti-theft device: ✓
Additional equipment: EDS(エレクトロニックディファレンシャルロックシステム) ESP(エレクトロニ&#1

Comfort

Air conditioner: Manual
Power window: ✓
Central switch: ✓
Steering column length: ✓
Steering column height: ✓
Cruise control: ×
Leather steering wheel: ×
Leather seats: —
Power front seat: ×
Power rear seat: ×
Wood panel: ×
Sunroof: ◯
Alloy wheels: Option settings YES
Folding seat: split
Glass w/ UV filter: ✓
Toned glasses: ×

Engine

Model: AVU
Type: inline 4 cylinder SOHC
Bore x stroke, mm: 81.0x77.4
Engine size, cc: 1595
Compression ratio: 10.3
Fuel injection: 電子制御
Max power, hp/rpm: 102ps(74kW)/5600rpm
Max torque, Nm/rpm: 15.1kg m(148N m)/3800rpm
Supercharger: ×
Fuel tank, liters: 55 l
Fuel: Unleaded premium gasoline
Fuel consumption, l/100km: 8.6

Steering & suspension

Steering: Power assist equipped rack&pinion
Front suspension: McPherson Strut (スタビライザーバー付)
Rear suspension: トーションビーム付トレーリングア
Front brake: Ventilated disk
Rear brake: disk
Front wheel: 195/65 R15
Rear wheel: 195/65 R15
Min turn diameter, m: 5.1

Gearbox

Number of stages: 4AT
Drive: FF
LSD: ----

Exterior equipment

Front fog lights: ×
Rear fog lights: ✓
Xenon: ×
Extra front lights: ×
Spoilers (f / r): × / ×
Wiper: ✓

Navigation & sound

Navigation: ×
Navigation device: It is not
Audio: AM/FM radio with MD player
CD player: ×

Gear ratios

CVT	1	2	3	4	5	6	7	Rev	Main
—	2.714	1.441	1.000	0.742	—	—	—	—	2.883

Available colors

black / Other blackwhitegreen / Other greenMaroon (brown)OliveNavy blue / Other Navy bluePurpleAshesYellowYellow-greenBlack (P)MagentaSilver / Other SilverRed / Other RedBlue / Other BlueDark cyanPearlGold
