VOLKSWAGEN GOLF CL

VOLKSWAGEN GOLF

1HAAZ · CL

Description

Modification: CL
Chassis ID: 1HAAZ
Dates releasing: 1994.1~
Base price, ¥: X-1HAAZ
Body size: 4020x1695x1420
Interior (LxWxH): ----x----x----
Wheelbase: 2475
Track f/r: 1465mm/1425mm
Full weight, kg: 1150
Body type: Hatch
Doors / seats: 5 door / 5

Safe equipment

Driver's air bag: ✓
Front passenger air bag: ✓
Side airbags: ×
ABS: ✓
TRC: ×
Belts w/ tensioner: ×
Belts w/ effort limiter: ×
Belts w/ holding: ✓
Child-seat fixation: ×
Safety planks: ✓
Brake assist: ×
Energy-absorbing body: ×
EBD: ×
Anti-theft device: ×
Additional equipment: ×

Comfort

Air conditioner: Manual
Power window: ✓
Central switch: ✓
Steering column length: ×
Steering column height: ×
Cruise control: ×
Leather steering wheel: ×
Leather seats: —
Power front seat: ×
Power rear seat: ×
Wood panel: ×
Sunroof: ◯
Alloy wheels: Option settings NO
Folding seat: 一体
Glass w/ UV filter: ×
Toned glasses: ×

Engine

Model: AAZ
Type: inline 4 cylinder SOHCturbo (Diesel)
Bore x stroke, mm: 79.5x95.5
Engine size, cc: 1896
Compression ratio: 22.5
Fuel injection: 分配 type 噴射ポンプ
Max power, hp/rpm: 73ps(----kW)/4200rpm
Max torque, Nm/rpm: 15.3kg m(----N m)/2400rpm
Supercharger: Turbo
Fuel tank, liters: 55 l
Fuel: Diesel
Fuel consumption, l/100km: 0

Steering & suspension

Steering: Power assist equipped rack&pinion
Front suspension: McPherson Strut /ロアウィッシュボーン
Rear suspension: トーションビーム付トレーリングア
Front brake: disk
Rear brake: Drum
Front wheel: 185/60R14 82H
Rear wheel: 185/60R14 82H
Min turn diameter, m: 5.0

Gearbox

Number of stages: 5MT
Drive: FF
LSD: ----

Exterior equipment

Front fog lights: ×
Rear fog lights: ✓
Xenon: ×
Extra front lights: ×
Spoilers (f / r): ✓ / ✓
Wiper: ✓

Navigation & sound

Navigation: ×
Navigation device: It is not
Audio: AM/FM radio with CS player
CD player: ×

Gear ratios

CVT	1	2	3	4	5	6	7	Rev	Main
—	3.454	1.944	1.285	0.909	0.745	—	—	—	3.166

Available colors

black / Other blackwhitegreenMaroon (brown)OliveNavy blue / Other Navy bluePurpleAshes / Other AshesYellowYellow-greenBlack (P)MagentaSilverRedBlueDark cyanPearlGold
