JDM Vehicle Catalog

Vehicle Specs

VOLKSWAGEN GOLF CLi

VOLKSWAGEN GOLF

1HADZ · CLi

Description

Modification: CLi
Chassis ID: 1HADZ
Dates releasing: 1995.1~
Base price, ¥: E-1HADZ
Body size: 4020x1695x1420
Interior (LxWxH): ----x----x----
Wheelbase: 2475
Track f/r: 1465mm/1425mm
Full weight, kg: 1060
Body type: Hatch
Doors / seats: 3 door / 5

Safe equipment

Driver's air bag: ✓
Front passenger air bag: ✓
Side airbags: ×
ABS: ✓
TRC: ×
Belts w/ tensioner: ✓
Belts w/ effort limiter: ×
Belts w/ holding: ✓
Child-seat fixation: ×
Safety planks: ✓
Brake assist: ×
Energy-absorbing body: ×
EBD: ×
Anti-theft device: ×
Additional equipment: ×

Comfort

Air conditioner: Manual
Power window: ×
Central switch: ✓
Steering column length: ×
Steering column height: ×
Cruise control: ×
Leather steering wheel: ×
Leather seats: —
Power front seat: ×
Power rear seat: ×
Wood panel: ×
Sunroof: ×
Alloy wheels: Option settings NO
Folding seat: 一体
Glass w/ UV filter: ×
Toned glasses: ×

Engine

Model: ADZ
Type: inline 4 cylinder SOHC
Bore x stroke, mm: 81.0x86.4
Engine size, cc: 1780
Compression ratio: 10.0
Fuel injection: 電子制御 type 燃料噴射装置(モノモトロ&
Max power, hp/rpm: 88ps(65kW)/5500rpm
Max torque, Nm/rpm: 14.5kg m(142.2N m)/2500rpm
Supercharger: ×
Fuel tank, liters: 55 l
Fuel: Unleaded premium gasoline
Fuel consumption, l/100km: 8.1

Steering & suspension

Steering: Power assist equipped rack&pinion
Front suspension: McPherson Strut (スタビライザーバー付)
Rear suspension: トーションビーム付トレーリングア
Front brake: disk
Rear brake: Drum
Front wheel: 185/60 R14
Rear wheel: 185/60 R14
Min turn diameter, m: 5.0

Gearbox

Number of stages: 5MT
Drive: FF
LSD: ----

Exterior equipment

Front fog lights: ×
Rear fog lights: ✓
Xenon: ×
Extra front lights: ×
Spoilers (f / r): ✓ / ✓
Wiper: ✓

Navigation & sound

Navigation: ×
Navigation device: It is not
Audio: It is not
CD player: ×

Gear ratios

CVT	1	2	3	4	5	6	7	Rev	Main
—	3.454	1.994	1.370	1.032	0.850	—	—	—	3.166

Available colors

blackwhitegreenMaroon (brown) / Other Maroon (brown)OliveNavy bluePurpleAshesYellowYellow-greenBlack (P)MagentaSilverRedBlue / Other BlueDark cyanPearlGold
