VOLKSWAGEN GOLF GTI 16V

VOLKSWAGEN GOLF

1HABF · GTI 16V

Description

Modification: GTI 16V
Chassis ID: 1HABF
Dates releasing: 1995.1~
Base price, ¥: E-1HABF
Body size: 4020x1710x1435
Interior (LxWxH): ----x----x----
Wheelbase: 2475
Track f/r: 1460mm/1440mm
Full weight, kg: 1200
Body type: Hatch
Doors / seats: 5 door / 5

Safe equipment

Driver's air bag: ✓
Front passenger air bag: ✓
Side airbags: ×
ABS: ✓
TRC: ×
Belts w/ tensioner: ✓
Belts w/ effort limiter: ×
Belts w/ holding: ✓
Child-seat fixation: ×
Safety planks: ✓
Brake assist: ×
Energy-absorbing body: ×
EBD: ×
Anti-theft device: ×
Additional equipment: ×

Comfort

Air conditioner: Manual
Power window: ✓
Central switch: ✓
Steering column length: ×
Steering column height: ✓
Cruise control: ×
Leather steering wheel: ✓
Leather seats: —
Power front seat: ×
Power rear seat: ×
Wood panel: ×
Sunroof: ◯
Alloy wheels: 15 inches standard
Folding seat: split
Glass w/ UV filter: ×
Toned glasses: ×

Engine

Model: ABF
Type: water cooling inline 4 cylinder DOHC 16-valves
Bore x stroke, mm: 82.5x92.8
Engine size, cc: 1984
Compression ratio: 10.5
Fuel injection: 電子制御 type 燃料噴射装置(デジファン&
Max power, hp/rpm: 145ps(107kW)/6000rpm
Max torque, Nm/rpm: 18.3kg m(179.5N m)/4800rpm
Supercharger: ×
Fuel tank, liters: 55 l
Fuel: Unleaded premium gasoline
Fuel consumption, l/100km: 8.1

Steering & suspension

Steering: Power assist equipped rack&pinion
Front suspension: McPherson Strut (スタビライザーバー付)
Rear suspension: トーションビーム付トレーリングア
Front brake: Ventilated disk
Rear brake: disk
Front wheel: 205/60 R15
Rear wheel: 205/50 R15
Min turn diameter, m: 5.1

Gearbox

Number of stages: 5MT
Drive: FF
LSD: ✓

Exterior equipment

Front fog lights: ✓
Rear fog lights: ✓
Xenon: ×
Extra front lights: ×
Spoilers (f / r): ✓ / ✓
Wiper: ✓

Navigation & sound

Navigation: ×
Navigation device: It is not
Audio: AM/FM radio with CS player
CD player: ×

Gear ratios

CVT	1	2	3	4	5	6	7	Rev	Main
—	3.300	1.944	1.416	1.029	0.837	—	—	—	3.060

Available colors

black / Other blackwhitegreenMaroon (brown)OliveNavy bluePurpleAshesYellowYellow-greenBlack (P)MagentaSilver / Other SilverRed / Other RedBlueDark cyanPearlGold
