JDM Vehicle Catalog

Vehicle Specs

VOLKSWAGEN NEW BEETLE EZ

VOLKSWAGEN NEW BEETLE

9CBFS · EZ

Description

Modification: EZ
Chassis ID: 9CBFS
Dates releasing: 2009.1~
Base price, ¥: ABA-9CBFS
Body size: 4130x1735x1500
Interior (LxWxH): ----x----x----
Wheelbase: 2515
Track f/r: 1510mm/1485mm
Full weight, kg: 1250
Body type: Coupe
Doors / seats: 3 door / 4

Safe equipment

Driver's air bag: ✓
Front passenger air bag: ✓
Side airbags: ✓
ABS: ✓
TRC: ×
Belts w/ tensioner: ✓
Belts w/ effort limiter: ✓
Belts w/ holding: ✓
Child-seat fixation: ✓
Safety planks: ✓
Brake assist: ×
Energy-absorbing body: ×
EBD: ✓
Anti-theft device: ✓
Additional equipment: ESP(エレクトロニックスタビリゼーション PRO グラム)

Comfort

Air conditioner: Manual
Power window: ✓
Central switch: ✓
Steering column length: ✓
Steering column height: ✓
Cruise control: ×
Leather steering wheel: ×
Leather seats: —
Power front seat: ×
Power rear seat: ×
Wood panel: ×
Sunroof: ×
Alloy wheels: Option settings NO
Folding seat: split
Glass w/ UV filter: ✓
Toned glasses: ×

Engine

Model: BFS
Type: inline 4 cylinder SOHC
Bore x stroke, mm: 81.0x77.4
Engine size, cc: 1595
Compression ratio: 10.3
Fuel injection: 電子制御
Max power, hp/rpm: 102ps(75kW)/5600rpm
Max torque, Nm/rpm: 15.1kg m(148N m)/3800rpm
Supercharger: ×
Fuel tank, liters: 55 l
Fuel: Unleaded premium gasoline
Fuel consumption, l/100km: 8.6

Steering & suspension

Steering: Other
Front suspension: McPherson Strut (stabilizer attaching)
Rear suspension: トーションビーム付トレーリングア
Front brake: Ventilated disk
Rear brake: disk
Front wheel: 205/55R16
Rear wheel: 205/55R16
Min turn diameter, m: 5.1

Gearbox

Number of stages: 6AT
Drive: FF
LSD: ----

Exterior equipment

Front fog lights: ×
Rear fog lights: ✓
Xenon: ×
Extra front lights: ×
Spoilers (f / r): × / ×
Wiper: ×

Navigation & sound

Navigation: ×
Navigation device: It is not
Audio: AM/FMラジオ
CD player: 単装

Gear ratios

CVT	1	2	3	4	5	6	7	Rev	Main
—	4.148	2.370	1.555	1.154	0.859	0.685	—	—	3.192

Available colors

black / Other blackwhite / Other whitegreenMaroon (brown)OliveNavy bluePurpleAshesYellow / Other YellowYellow-greenBlack (P)MagentaSilver / Other SilverRed / Other RedBlueDark cyanPearlGold / Other Gold
