JDM Vehicle Catalog

Vehicle Specs

VOLKSWAGEN PASSAT W8 4MOTION

VOLKSWAGEN PASSAT

3BBDNF · W8 4MOTION

Description

Modification: W8 4MOTION
Chassis ID: 3BBDNF
Dates releasing: 2004.4~
Base price, ¥: GH-3BBDNF
Body size: 4700x1745x1460
Interior (LxWxH): ----x----x----
Wheelbase: 2700
Track f/r: 1495mm/1495mm
Full weight, kg: 1750
Body type: Sedan
Doors / seats: 4 door / 5

Safe equipment

Driver's air bag: ✓
Front passenger air bag: ✓
Side airbags: ✓
ABS: ✓
TRC: ×
Belts w/ tensioner: ✓
Belts w/ effort limiter: ✓
Belts w/ holding: ✓
Child-seat fixation: ✓
Safety planks: ✓
Brake assist: ✓
Energy-absorbing body: ×
EBD: ✓
Anti-theft device: ✓
Additional equipment: ESP(エレクトロニックスタビリティ PRO グラム) EDS(エレクトロニックディファ&#1252

Comfort

Air conditioner: Full Auto
Power window: ✓
Central switch: ✓
Steering column length: ✓
Steering column height: ✓
Cruise control: ✓
Leather steering wheel: ×
Leather seats: —
Power front seat: ✓
Power rear seat: ×
Wood panel: ✓
Sunroof: ◯
Alloy wheels: 17 inches standard
Folding seat: ×
Glass w/ UV filter: ✓
Toned glasses: ✓

Engine

Model: BDN
Type: W型 8 cylinder SOHC 32-valves
Bore x stroke, mm: 84.0x90.2
Engine size, cc: 3998
Compression ratio: 10.7
Fuel injection: 電子制御
Max power, hp/rpm: 275ps(202kW)/6000rpm
Max torque, Nm/rpm: 37.7kg m(370N m)/2750rpm
Supercharger: ×
Fuel tank, liters: 80 l
Fuel: Unleaded premium gasoline
Fuel consumption, l/100km: 14.7

Steering & suspension

Steering: Power assist equipped rack&pinion
Front suspension: 4リンク(スタビライザーバー付)
Rear suspension: Double wishbone (スタビライザーバー付)
Front brake: Ventilated disk
Rear brake: Ventilated disk
Front wheel: 225/45 R17
Rear wheel: 225/45 R17
Min turn diameter, m: 5.4

Gearbox

Number of stages: 5AT
Drive: Full-time 4WD
LSD: ----

Exterior equipment

Front fog lights: ✓
Rear fog lights: ✓
Xenon: ✓
Extra front lights: ×
Spoilers (f / r): × / ×
Wiper: ×

Navigation & sound

Navigation: ✓
Navigation device: DVD
Audio: AM/FM radio with MD player
CD player: ×

Gear ratios

CVT	1	2	3	4	5	6	7	Rev	Main
—	3.664	1.998	1.406	1.000	0.742	—	—	—	4.095

Available colors

black / Other blackwhitegreen / Other greenMaroon (brown)OliveNavy blue / Other Navy bluePurpleAshes / Other AshesYellowYellow-greenBlack (P)MagentaSilver / Other SilverRedBlueDark cyanPearlGold
