VOLVO S40 CLASSIC

VOLVO S40

4B4204 · CLASSIC

Description

Modification: CLASSIC
Chassis ID: 4B4204
Dates releasing: 2004.4~
Base price, ¥: GH-4B4204
Body size: 4515x1720x1420
Interior (LxWxH): ----x----x----
Wheelbase: 2560
Track f/r: 1470mm/1475mm
Full weight, kg: 1360
Body type: Sedan
Doors / seats: 4 door / 5

Safe equipment

Driver's air bag: ✓
Front passenger air bag: ◯
Side airbags: ✓
ABS: ✓
TRC: ✓
Belts w/ tensioner: ✓
Belts w/ effort limiter: ×
Belts w/ holding: ✓
Child-seat fixation: ×
Safety planks: ×
Brake assist: ×
Energy-absorbing body: ×
EBD: ✓
Anti-theft device: ✓
Additional equipment: DSA(ダイナミックスタビリティアシスタンス) IC/インフレータブルカーテン(&#3

Comfort

Air conditioner: Full Auto
Power window: ✓
Central switch: ✓
Steering column length: ×
Steering column height: ✓
Cruise control: ×
Leather steering wheel: ✓
Leather seats: —
Power front seat: ✓
Power rear seat: ×
Wood panel: ✓
Sunroof: シングル
Alloy wheels: 15 inches standard
Folding seat: split
Glass w/ UV filter: ×
Toned glasses: ×

Engine

Model: B4204( TURBO 付)
Type: water cooling inline 4 cylinder DOHC 16-valves IC-turbo
Bore x stroke, mm: 83.0x90.0
Engine size, cc: 1947
Compression ratio: 9.0
Fuel injection: EMS2000
Max power, hp/rpm: 163ps(120kW)/5250rpm
Max torque, Nm/rpm: 24.5kg m(240N m)/1800~4500rpm
Supercharger: IC turbo
Fuel tank, liters: 60 l
Fuel: Unleaded premium gasoline
Fuel consumption, l/100km: 11.1

Steering & suspension

Steering: Power assist equipped rack&pinion
Front suspension: McPherson Strut type
Rear suspension: マルチリンク
Front brake: Ventilated disk
Rear brake: disk
Front wheel: 205/50R15
Rear wheel: 205/50R15
Min turn diameter, m: ----

Gearbox

Number of stages: 5AT
Drive: FF
LSD: ----

Exterior equipment

Front fog lights: ✓
Rear fog lights: ✓
Xenon: ×
Extra front lights: ×
Spoilers (f / r): ✓ / ✓
Wiper: ×

Navigation & sound

Navigation: ×
Navigation device: It is not
Audio: AM/FM radio with MD player
CD player: 単装

Gear ratios

CVT	1	2	3	4	5	6	7	Rev	Main
—	—	—	—	—	—	—	—	—	----

Available colors

blackwhitegreen / Other greenMaroon (brown)OliveNavy bluePurpleAshesYellowYellow-greenBlack (P)MagentaSilver / Other SilverRed / Other RedBlue / Other BlueDark cyanPearlGold
