VOLVO V40 CROSS COUNTRY T5 AWD

VOLVO V40

MB5204T · CROSS COUNTRY T5 AWD

Description

Modification: CROSS COUNTRY T5 AWD
Chassis ID: MB5204T
Dates releasing: 2014.4~
Base price, ¥: DBA-MB5204T
Body size: 4370x1800x1470
Interior (LxWxH): ----x----x----
Wheelbase: 2645
Track f/r: 1550mm/1540mm
Full weight, kg: 1580
Body type: Wagon
Doors / seats: 5 door / 5

Safe equipment

Driver's air bag: ✓
Front passenger air bag: ✓
Side airbags: ✓
ABS: ✓
TRC: ✓
Belts w/ tensioner: ✓
Belts w/ effort limiter: ×
Belts w/ holding: ✓
Child-seat fixation: ×
Safety planks: ×
Brake assist: ×
Energy-absorbing body: ×
EBD: ✓
Anti-theft device: ✓
Additional equipment: スポーツモード付DSTC(ダイナミックスタビリティ&トラクションコントロ&#12540

Comfort

Air conditioner: Full Auto
Power window: ✓
Central switch: ×
Steering column length: ✓
Steering column height: ✓
Cruise control: ✓
Leather steering wheel: ✓
Leather seats: —
Power front seat: ✓
Power rear seat: ×
Wood panel: ×
Sunroof: ◯
Alloy wheels: 17 inches standard
Folding seat: split
Glass w/ UV filter: ×
Toned glasses: ×

Engine

Model: B5204T
Type: water cooling inline 5 cylinder DOHC 20-valves IC-turbo
Bore x stroke, mm: 81.0x77.0
Engine size, cc: 1983
Compression ratio: 10.5
Fuel injection: 電子燃料噴射
Max power, hp/rpm: 213ps(157kW)/6000rpm
Max torque, Nm/rpm: 30.6kg m(300N m)/2700~5000rpm
Supercharger: IC turbo
Fuel tank, liters: 57 l
Fuel: Unleaded premium gasoline
Fuel consumption, l/100km: 8.1

Steering & suspension

Steering: Power assist equipped rack&pinion
Front suspension: McPherson Strut type
Rear suspension: マルチリンク
Front brake: Ventilated disk
Rear brake: disk
Front wheel: 225/50R17
Rear wheel: 225/50R17
Min turn diameter, m: 5.4

Gearbox

Number of stages: 6AT
Drive: Full-time 4WD
LSD: ----

Exterior equipment

Front fog lights: ×
Rear fog lights: ×
Xenon: ✓
Extra front lights: ×
Spoilers (f / r): ✓ / ✓
Wiper: ✓

Navigation & sound

Navigation: ◯
Navigation device: HDD
Audio: AM/FMラジオ
CD player: 単装

Gear ratios

CVT	1	2	3	4	5	6	7	Rev	Main
—	4.148	2.370	1.556	1.155	0.859	0.686	—	—	3.394

Available colors

black / Other blackwhite / Ice WhitegreenMaroon (brown) / Other Maroon (brown)OliveNavy blue / Other Navy bluePurpleAshes / Other AshesYellowYellow-greenBlack (P) / Other Black (P)MagentaSilver / Other SilverRed / Other RedBlue / Other BlueDark cyanPearl / Crystal White PearlGold / Other Gold
