VOLVO XC70 NORDIC

VOLVO XC70

SB5254AWL · NORDIC

Description

Modification: NORDIC
Chassis ID: SB5254AWL
Dates releasing: 2006.9~
Base price, ¥: CBA-SB5254AWL
Body size: 4760x1860x1560
Interior (LxWxH): ----x----x----
Wheelbase: 2765
Track f/r: 1610mm/1550mm
Full weight, kg: 1710
Body type: SUV
Doors / seats: 5 door / 5

Safe equipment

Driver's air bag: ✓
Front passenger air bag: ✓
Side airbags: ✓
ABS: ✓
TRC: ✓
Belts w/ tensioner: ✓
Belts w/ effort limiter: ×
Belts w/ holding: ✓
Child-seat fixation: ×
Safety planks: ✓
Brake assist: ✓
Energy-absorbing body: ×
EBD: ✓
Anti-theft device: ✓
Additional equipment: DSTC(ダイナミックスタビリティ&トラクションコントロール) IC/インフレータ&#

Comfort

Air conditioner: Full Auto
Power window: ✓
Central switch: ✓
Steering column length: ✓
Steering column height: ✓
Cruise control: ✓
Leather steering wheel: ✓
Leather seats: —
Power front seat: ✓
Power rear seat: ×
Wood panel: ✓
Sunroof: シングル
Alloy wheels: 16 inches standard
Folding seat: split
Glass w/ UV filter: ×
Toned glasses: ×

Engine

Model: B5254( TURBO 付)
Type: water cooling inline 5 cylinder DOHC 20-valves IC-turbo
Bore x stroke, mm: 83.0x93.2
Engine size, cc: 2521
Compression ratio: 9.0
Fuel injection: 電子燃料噴射
Max power, hp/rpm: 209ps(154kW)/5000rpm
Max torque, Nm/rpm: 32.6kg m(320N m)/1500~4500rpm
Supercharger: IC turbo
Fuel tank, liters: 72 l
Fuel: Unleaded premium gasoline
Fuel consumption, l/100km: 11.1

Steering & suspension

Steering: Power assist equipped rack&pinion
Front suspension: McPherson Strut type
Rear suspension: Multi-link
Front brake: disk
Rear brake: disk
Front wheel: 215/65R16
Rear wheel: 215/65R16
Min turn diameter, m: 5.7

Gearbox

Number of stages: 5AT
Drive: Full-time 4WD
LSD: ----

Exterior equipment

Front fog lights: ×
Rear fog lights: ✓
Xenon: ✓
Extra front lights: ×
Spoilers (f / r): × / ×
Wiper: ✓

Navigation & sound

Navigation: ✓
Navigation device: HDD
Audio: AM/FM radio with MD player
CD player: 単装

Gear ratios

CVT	1	2	3	4	5	6	7	Rev	Main
—	4.657	3.032	1.982	1.341	1.018	—	—	—	5.114

Available colors

black / Other blackwhite / Ice Whitegreen / Other greenMaroon (brown) / Other Maroon (brown)OliveNavy blue / Other Navy bluePurpleAshes / Other AshesYellowYellow-green / Other Yellow-greenBlack (P)MagentaSilverRedBlueDark cyanPearlGold / Other Gold
