VOLVO XC70 T5 CLASSIC

VOLVO XC70

BB420XC · T5 CLASSIC

Description

Modification: T5 CLASSIC
Chassis ID: BB420XC
Dates releasing: 2015.7~
Base price, ¥: DBA-BB420XC
Body size: 4840x1890x1605
Interior (LxWxH): ----x----x----
Wheelbase: 2815
Track f/r: 1605mm/1570mm
Full weight, kg: 1780
Body type: SUV
Doors / seats: 5 door / 5

Safe equipment

Driver's air bag: ✓
Front passenger air bag: ✓
Side airbags: ✓
ABS: ✓
TRC: ×
Belts w/ tensioner: ✓
Belts w/ effort limiter: ✓
Belts w/ holding: ✓
Child-seat fixation: ×
Safety planks: ✓
Brake assist: ✓
Energy-absorbing body: ×
EBD: ✓
Anti-theft device: ✓
Additional equipment: SIPS(側面衝撃吸収システム) IC-インフレータブルカーテン(頭部側面衝撃吸収&#12

Comfort

Air conditioner: Full Auto
Power window: ✓
Central switch: ✓
Steering column length: ✓
Steering column height: ✓
Cruise control: ✓
Leather steering wheel: ×
Leather seats: —
Power front seat: ✓
Power rear seat: ×
Wood panel: ✓
Sunroof: シングル
Alloy wheels: 17 inches standard
Folding seat: split
Glass w/ UV filter: ×
Toned glasses: ✓

Engine

Model: B420
Type: water cooling inline 4 cylinder DOHC 16-valves IC-turbo
Bore x stroke, mm: 82.0x93.2
Engine size, cc: 1968
Compression ratio: 10.8
Fuel injection: 電子燃料噴射
Max power, hp/rpm: 245ps(180kW)/5500rpm
Max torque, Nm/rpm: 35.7kg m(350N m)/1500~4800rpm
Supercharger: IC turbo
Fuel tank, liters: 70 l
Fuel: Unleaded premium gasoline
Fuel consumption, l/100km: 6.9

Steering & suspension

Steering: Power assist equipped rack&pinion
Front suspension: McPherson Strut type
Rear suspension: Multi-link
Front brake: disk
Rear brake: disk
Front wheel: 235/55R17
Rear wheel: 235/55R17
Min turn diameter, m: 5.7

Gearbox

Number of stages: 8AT
Drive: FF
LSD: ----

Exterior equipment

Front fog lights: ✓
Rear fog lights: ✓
Xenon: ✓
Extra front lights: ×
Spoilers (f / r): ✓ / ×
Wiper: ✓

Navigation & sound

Navigation: ✓
Navigation device: HDD
Audio: AM/FMラジオ
CD player: 単装

Gear ratios

CVT	1	2	3	4	5	6	7	Rev	Main
—	5.250	3.029	1.950	1.457	1.221	1.000	0.809	0.673	4.015

Available colors

black / Other blackwhite / Ice WhitegreenMaroon (brown) / Other Maroon (brown)OliveNavy blue / Other Navy bluePurpleAshes / Other AshesYellowYellow-greenBlack (P)MagentaSilver / Other SilverRedBlueDark cyanPearl / Crystal White PearlGold
